Cambium 3GHz PMP 450i Integrated High Gain SM
US$924.26
- SKU: C030045C002A
- Manufacturer: Cambium Networks
- Data Sheet: Download
Product Information
Cambium Networks C030045C002A
3GHz PMP 450i Integrated High Gain SM
Cambium Networks 3 GHz connectorized access point is part of the industry leading PMP 450i product line. It is the most scalable industrial-grade wireless broadband solution available. This model has an integrated dual slant 19 dBi antenna.
Features:
- Ultra-Wide Band: Radios support the entire band, advanced radio design improves transmit power and increases receive sensitivity.
- Rugged Metal Enclosure: Designed to meet IP-66 and IP-67 standards to withstand harsh environments.
- Dynamic Interference Filtering: Provides industry leading noise isolation for improved performance.
- Updated FPGA and SoC architecture triples the processing power compared to PMP 450.
- Multi-function AUX Power: Allows for greater flexibility for deployment by adding a camera or other PoE directly.
Specifications
Specifications C030045C002A
| Channel Spacing | Configurable on 2.5 MHz increments, 3 GHz customizable to 50 KHz |
| Frequency Range | 3300 to 3900 MHz |
| Channel Width | 5 / 7 / 10 / 15 / 20 / 30 MHz |
| MAC (Media Access Control) Layer | Cambium Networks proprietary |
| Physical Layer | 2x2 MiMO OFDM |
| Ethernet Interface | 100/1000BaseT, full duplex, rate auto negotiated (802.3 compliant) |
| Protocols Used | IPv4, UDP, TCP, IP, ICMP, Telnet, SNMP, HTTP, FTP |
| Network Management | HTTP, HTTPS, Telnet, FTP, SNMP v3 |
| VLAN | 802.1ad (DVLAN Q-inQ), 802.1Q with 802.1p priority, dynamic port VID |
| ARQ | Yes |
| Maximum Deployment Range | Up to 40 miles (64 km) |
| Latency | 3 - 5 ms, typical |
| GPS Synchronization | Yes, via Autosync (CMM3, CMM4) |
| Quality of Service | Diffserve QoS |
| Antenna Beam Width | 10° azimuth for integrated antenna |
| Antenna Gain | 19 dBi dual slant integrated antenna |
| Transmit Power Range | 40 dB dynamic range (to EIRP limit by region)(1 dB step) |
| Maximum Transmit Power | 25 dBm combined output |
| Surge Suppression | EN6100-4-5:1.2us, 500 V voltage waveform |
| Mean Time Between Failure | > 40 Years |
| Environmental | IP66, IP67 |
| Temperature / Humidity | -40 to 60°C (-40 to 140°F), 0 to 95% non-condensing |
| Weight | Approx. 2.5 kg (5.5 lbs) |
| Wind Survival | 200 km/h (124 mph) |
| Dimensions | 31.0 x 31.0 x 6.4 cm (12 x 12 x 2.5 ") |
| Power Consumption | 15 W typical, 25 W max, 55 W max with Aux port PoE out enabled |
| Input Voltage | 48 - 59 VDC, 802.3at compliant |
| Mounting | Wall or Pole mountable |
| Encryption | 56-bit DES, FIPS-197 128-bit AES |
| CE | EN 302 326-2 v1.2.2 / EN 302 326-3 v1.3.1 |
