  • Cambium PTP 820S Radio 6LGHz, TR65A, Ch1W3, Lo, 5725-5755MHz

Cambium PTP 820S Radio 6LGHz, TR65A, Ch1W3, Lo, 5725-5755MHz

(0)No Reviews yet
US$‎3,675.00
  • SKU: C060082B002A
  • Manufacturer: Cambium Networks
  • Data Sheet: Download

Out of Stock

Call for Availability

Product Information

Cambium Networks C060082B002A

PTP 820S Radio 6LGHz, TR65A, Ch1W3, Lo, 5725-5755MHz

PTP 820 is a point-to-point licensed microwave backhaul platform that integrates leading networking functionality with the industry’s most advanced microwave technologies creating a superior microwave transport solution. Supporting licensed frequency bands ranging from 6 to 42 GHz, the PTP 820 series delivers a wide range of configurations to offer a tailored solution for any deployment scenario. Composed of high-density multi-technology nodes and integrated radio units, the PTP 820 series offers flexibility in choosing all-indoor, split-mount and all-outdoor configuration options. Exploiting unique Line of Sight (LOS) Multiple Input Multiple Output (MIMO) technology, modulation up to 2048QAM and wider channel bandwidths, ensures Industry leading throughput and spectral efficiency.

Specifications

Specifications C060082B002A

Radio ModelTR65A,Ch1W3,Lo,5725-5755MHz
Licensed Radio Series PTP 820S
Network Protocol IP
Broadband System Configuration All Outdoor
Broadband Frequency Band 6 GHz
Frequency Range 5790-5820 MHz
Sub Band Hi
Data Rate 605 Mbit/s
Maximum Data Rate 833 Mbit/s
Carrier Aggregation Single Carrier
Modulation QPSK to 2048 QAM w/ACM
Interface 1 x 10/100/1000Base-T and 1x1000base-X or 10/100/1000Base-T
Security/Encryption Not Specified
Compression No
Proprietary Antenna Interface Not Specified
Operating Voltage -48VDC
Channel Bandwidth 28,56,30,40,50,60,80 MHz
Temperature Range -33-55 deg C
