L-com 2.4GHz 5dBi Rubber Duck Antenna, RP-SMA Plug Connector
US$10.95
- SKU: HG2405RD-RSP
- Manufacturer: L-Com
Product Information
L-com HG2405RD-RSP 2.4 GHz 5 dBi Rubber Duck Antenna - RP-SMA Plug Connector
This compact 2.4 GHz omnidirectional "rubber-duck" WiFi antenna provides broad coverage and 5.5 dBi gain. It is a coaxial sleeve design with an omni-directional pattern. It is ideally suited for IEEE 802.11b, 802.11g and 802.11n wireless LANs, Bluetooth® and other WLAN applications.
Measuring 8.2" long, this flexible antenna features a tilt-and-swivel reverse-polarity SMA connector, allowing them to be used vertically, at a right angle, or any angle in-between. It is suitable as a replacement RF antenna for many access points and radios that are equipped with reverse-polarity SMA connectors including D-Link®, Linksys® WET11 and others.
Specifications
Specifications HG2405RD-RSP
| Frequency | 2400-2500 MHz |
| Gain | 5.5 dBi |
| Impedance | 50 Ohm |
| VSWR | < 2.0 |
| Weight | 0.7 oz. (20 g) |
| Length | 8.2" (208 mm) |
| Diameter | 0.5" (13 mm) |
| Finish | Matte Black |
| Connector | Reverse Polarity SMA Plug |
| Operating Temperature | -40° C to 85° C (-40° F to 185° F) |
| Flame Rating | UL 94HB |
| Polarization | Vertical |
| RoHS Compliant | Yes |
