Tripp Lite SmartPro 1500VA 1000W LI Sine Wave UPS 2U Rack/Tower LCD Display USB, DB9 Serial
- SKU: SMC15002URM
- Manufacturer: Tripp Lite
- Data Sheet: Download
Product Information
Tripp Lite SMC15002URM
Tripp Lite SmartPro 1500VA 1000W LI Sine Wave UPS 2U Rack/Tower LCD Display USB, DB9 Serial
Line-interactive, uninterruptible power supply (UPS) with enhanced LCD interface offers network-grade power protection for your critical server, network and telecommunications equipment. UPS with built-in, auto-voltage regulation (AVR) actively corrects brownouts and overvoltages back to usable levels while maintaining a full battery charge in case of a power failure. Interactive LCD interface reports UPS operating mode, detailed UPS and site-power data, plus enables a variety of UPS setup and configuration options. Super-fast switchover from line to battery power occurs within milliseconds to maintain operation of connected equipment without interruption. 94 percent line-mode efficiency offers reduced heat emissions and operating costs. USB and RS-232 ports work with PowerAlert software to communicate detailed UPS status and site power conditions. Communications ports enable detailed monitoring of equipment load levels, self-test data and utility power conditions.
Specifications
Specifications SMC15002URM
General Information | |
Product Name | SmartPro 1500VA 1000W LI Sine Wave UPS 2U Rack/Tower LCD Display USB, DB9 Serial |
Product Line | SmartPro |
Product Model | SMC15002URM |
Packaged Quantity | 1 Each |
Product Type | Line-interactive UPS |
Technical Information | |
Receptacles | 8 x NEMA 5-15R |
Battery Information | |
Backup / Run Time (Full Load) | 6.50 Minute |
Power Description | |
Load Capacity (VA) | 1500 VA |
Load Capacity (Watt) | 1000 W |
Input Voltage | 120 V AC |
Output Voltage | 120 V AC |
Physical Characteristics | |
Height | 3.5" |
Width | 17.3" |
Depth | 13.5" |
Rack Height | 2U |
Form Factor | Tower/Rack Mountable |
Miscellaneous | |
Environmentally Friendly | Yes |
Environmental Certification | RoHS |
Country of Origin | China |
Other Information | |
Product Family | SmartPro |
Backup / Run Time (Half Load) | 17.70 Minute |
Battery Management | user-replaceable |
USB | Yes |
Serial Port | Yes |
Cord Length | 9.84 ft |
Recycled | No |
Recycled Content | 0 |
Post-consumer-waste% | 0 |
Alarm | UPS StartUp, Power Failure, Low Battery, Overload, UPS Fault, Remote Shutdown |
Certifications & Standards | Meets FCC Part 15 Category A (EMI), Tested to CSA (Canada), Tested to NOM (Mexico), Tested to UL1778 (USA) |
Circuit Breaker | Yes |
Plug / Connector Type | NEMA 5-15P |
Emergency Power OFF | Yes |
Status Indicators | LEDs |
Input Current | 0 |
Protection Type | Brownout, Over Voltage, Surge, Black Out, Under Voltage, EMI / RFI |
Surge Energy Rating | 570 J |
Temperature | 104°F (40°C) |
Thermal Dissipation | 223 BTU/h |
Waveform Type | Sine Wave, Pure Sine Wave |
Hot Swappable | Yes |
Sound Emission | 45 dB(A) |
