Product Information

Ubiquiti ES-16-150W

Ubiquiti Networks EdgeSwitch 16-Port 150-Watt Managed PoE+ Gigabit Switch with SFP

Advanced Switching Technology

Build and expand your network with Ubiquiti Networks EdgeSwitch, part of the EdgeMAX line of products. The EdgeSwitch is a fully managed, PoE+ Gigabit switch, delivering robust performance and intelligent switching for growing networks. The EdgeSwitch offers an extensive suite of advanced Layer-2 switching features and protocols, and also provides Layer-3 routing capability.

Switching Performance

The EdgeSwitch offers the forwarding capacity to simultaneously process traffic on all ports at line rate without any packet loss. For its total, non-blocking throughput, the 16-port models support up to 18 Gbps.

PoE+ Flexibility

This EdgeSwitch PoE Gigabit Ethernet switch offers 16 ports of auto-sensing IEEE 802.3af/at and configurable 24V Passive PoE to simplify your infrastructure. By default, the EdgeSwitch automatically detects 802.3af/at devices so they automatically receive PoE. For 24V Passive PoE devices, manually enable 24V passive PoE using the EdgeSwitch Configuration Interface.

Fiber Connectivity

The EdgeSwitch provides fiber connectivity options for your growing networks. This 16-port model includes two SFP ports, providing up to 1 Gbps uplinks.

Comprehensive User Interface

Designed for convenient management, the EdgeSwitch Configuration Interface allows administrators to configure and monitor switch features in a graphical user interface. For advanced users, an industry-standard command-line interface (CLI) is available through telnet and SSH.

Powerful Functionality

The EdgeSwitch uses a sophisticated operating system that provides basic switching features, PoE configuration per port, and a variety of advanced features including:

  • MSTP/RSTP/STP
  • VLAN, Private VLAN, Voice VLAN
  • Link Aggregation
  • DHCP Snooping, IGMP Snooping
  • TACACS+, RADIUS, 802.1X, MAC Filtering, ACL
  • DiffServ, CoS
  • Static Routing, Policy-Based Routing

Specifications

Specifications ES-16-150W

Dimensions443 x 43 x 221 mm (17.44 x 1.69 x 8.70")
WeightWithout Mount Bracket : 2.80 kg (6.17 lb), With Mount Bracket : 2.89 kg (6.37 lb)
Total Non-Blocking Throughput18 Gbps
Switching Capacity36 Gbps
Forwarding Rate26.78 Mpps
Max. Power ConsumptionIncludes PoE Output: 150W, Excludes PoE Output: 28W
Power Method100-240VAC/50-60 Hz, Universal Input
Power SupplyAC/DC, Internal, 150W DC
LEDs Per PortRJ45 Data Ports: PoE, Speed/Link/Activity, SFP Data Ports: Speed/Link/Activity
Networking Interfaces(16) 10/100/1000 Mbps RJ45 Ethernet Ports (2) 1 Gbps SFP Ethernet Ports
Management Interface(1) RJ45 Serial Port, Ethernet In/Out Band
CertificationsCE, FCC, IC
RackmountYes, 1U High
ESD/EMP ProtectionAir: ±24 kV, Contact: ±24 kV
Operating Temperature-5 to 40° C (23 to 104° F)
Operating Humidity5 to 95% Noncondensing
Shock and VibrationETSI300-019-1.4 Standard
PoE Per Port
PoE InterfacesPOE+ IEEE 802.3af/at (Pins 1, 2+; 3, 6-) 24VDC Passive PoE (Pins 4, 5+; 7, 8-)
Max. PoE+ Wattage per Port by PSE34.2W
Voltage Range 802.3at Mode50–57V
Max. Passive PoE Wattage per Port17W
24V Passive PoE Voltage Range20-27V
