Mikrotik Dual chain 5GHz system with Gigabit Ethernet and 802.11ac support for long distance links

  • SKU: RBLDFG-5acD
  • Manufacturer: MikroTik
  • Data Sheet: Download
  • User Guide: Download
  • Block Diagram: Download
  • Availability: Call for Availability This item can sometimes be sourced and shipped direct from other locations when out of stock. Email me when this product is in stock!
US$‎58.00

MikroTik RouterBOARD RBLDFG-5acD (International Version)

LDF ac with 802.11ac and Gigabit Ethernet

We are adding a new model to our LDF (Lite Dish Feed) product family - LDF 5 ac with a Gigabit Ethernet port and 802.11ac support! It's an outdoor 5Ghz wireless system with a built in antenna, meant to be installed on satellite offset dish antennas. You can use any available satellite TV dish with an offset mount to quickly deploy powerful long range wireless links.

The offset mount is universal at 40 mm diameter, and the LDF can easily be placed inside it. Since the LDF itself is a tiny little package, it makes shipping and deployment simple and low cost.

There are two models available, the LDF 5 is lower cost and has 802.11n with a 10/100Mbit port, while the LDF 5 ac has a higher speed CPU, more RAM, has a Gigabit port and supports 802.11ac for higher throughput.

Using a dish of up to 100 cm in diameter, it is possible to obtain antenna amplification of up to 33 dBi. The device comes preinstalled with RouterOS and is ready to use.

    Specifications RBLDFG-5acD

    CPUIPQ-4018 716 MHz
    Memory256 MB
    Storage 16 MB Flash
    Ethernet ports One 10/100/1000 Mbit/s Gigabit Ethernet
    WirelessIPQ-4018, wireless built-in 5 GHz 802.11ac, dual chain
    Wireless chip model AR9344
    Operating frequency International: 5150 MHz-5875 MHz
    USA: 5170-5250 MHz; 5725-5835 MHz
    Power optionsPassive PoE input 10-30 V
    Consumption8 W
    Antenna beam width60°
    Internal antenna gain9 dBi
    Dimensions84mm x 84mm x 115mm
    Operating temperature-40°C .. +70°C
    LEDs8x LEDs (5x user LEDs)
    License level 3
