Product Information
Ubiquiti Networks UACC-UK-Ultra-Panel-Antenna
Panel Antenna Ultra
Sleek, clip-on external antenna for the Swiss Army Knife Ultra that provides 90-degree directional, extended range coverage.
Features:
- High-efficiency 90° directional radiation pattern.
- Optimized for dual-band, extended range coverage.
- Clip-on attachment with support for all Swiss Army Knife Ultra mounting methods.
- Weatherproof (outdoor exposed).
Specifications
Specifications UACC-UK-Ultra-Panel-Antenna
| Dimensions | 138 x 207 x 43 mm (5.4" x 8.1" x 1.7") |
| Weight | 450 g (1 lb) |
| Enclosure materials | UV-stabilized polycarbonate, aluminum |
| Mounting | 1~2" on pipe outer diameter Compatible with the UK-Ultra |
| Wind survivability | 75 N at 200 km/h (16.7 lbf at 125 mph) |
| Weatherproofing | IPX6 |
| Antenna gain 2.4 GHz 5 GHz | 10 dBi 15 dBi |
