Cambium XV3-8 Tri-Radio Wi-Fi 6 Indoor Access Point (US Version)
- SKU: XV3-8X00A00-US
- Manufacturer: Cambium Networks
- Data Sheet: Download
Product Information
Cambium Networks XV3-8X00A00-US
XV3-8 Tri-Radio Wi-Fi 6 Indoor AP, SDR 802.11ax 8x8 or Dual 4x4 5GHz, and 2.4GHz WLAN Access Point with Integrated Antennas, scan radio, BLE. (US Version)
XV3-8 Wi-Fi 6 Access Point - 802.11ax Tri-Radio 8x8 Access Point with Software-Defined Radios
- High-density Wi-Fi with software-defined radios (SDR)
- Five-radio architecture for edge services
- 6 Gbps aggregate data rate
- Dedicated scanning sensor, dual band
- Application policy control
- EasyPass with Microsoft Azure and Google G Suite integration
DESIGNED FOR HIGH DENSITY AND EDGE SERVICES
The XV3-8 features a total of five (5) radios to deliver a next generation network with edge services with high capacity and high density. Three data radios can be configured as two 5 GHz 4x4 plus one 2.4 GHz 4x4, or the two 5 GHz radios can be combined into a single 5 GHz 8x8 radio with the maximum power and performance of the 802.11ax standard. A dedicated network scanning radio provides continuous network monitoring to enhance security protocols, detailed network reports, and automatic RF optimizations. Add the Bluetooth Smart 4.1 IoT radio for BLE-based location services and you get a multi-radio, high-capacity Wi-Fi 6 AP designed for the most demanding networks in enterprise, education, retail, and public venues.
XV3-8 comes with Limited Lifetime Warranty providing return and repair service on the access point from date of purchase until end of life of the product.
OPTIMIZED WI-FI FOR DOMINANT CLIENT DEVICES
For networks dominated by legacy 802.11ac client devices, the dual 5 GHz 4x4 mode will double network capacity to maintain high-bitrate services as density increases. As the devices migrate to the new Wi-Fi 6 standard based on 802.11ax, the XV3-8 SDR can be quickly converted into full 8x8 operating mode via a simple configuration change. No firmware change is required to support this mode.
CLOUD AND ON-PREMISES MANAGEMENT
XV3-8 operates with either Cambium Networks' XMS or cnMaestroTM management system. Choose the management system that best fits your business and use the latest technology from Cambium Networks.
Specifications
Specifications XV3-8X00A00-US
| FCC | Ch 1-11, 36-48, 52-64, 100-144, 149-165 |
| ISED | Ch 1-11, 36-48, 52-64, 100-144, 149-165 |
| ETSI | Ch 1-13, 32-48, 52-64, 100-144 |
| ROW | (Individual country limits may apply) Ch 1-14, 36-48, 52-64, 100-144, 149-165 |
| Radios | 2.4 GHz: 802.11 b/g/n/ax, 4x4 5 GHz: 802.11 a/n/ac Wave 2/ax, 8x8 (or configure as two 4x4) 2.4/5 GHz scan, 1x1 BLE 4.1 |
| Wi-Fi | 802.11 a/b/g/n/ac Wave 2/ax |
| SSID Security | WPA3, WPA2 (CCMP, AES, 802.11i), WPA2 Enterprise (802.1x/EAP), WPA PSK (TKIP), Open |
| Max PHY Rate | 2.4 GHz: 1,147 Mbps 5 GHz: 4,804 Mbps |
| Ports | 1 x IEEE 802.3 10/100/1000 Mbps 1 x IEEE 802.3bz 100/1000/2500/5000 Mbps Auto sensing MDIX 1 x USB 3.0 |
| Antenna | 2.4 GHz: 5 dBi 5 GHz: 6.7dBi 2.4/5 GHz: sensor 5 dBi / 6.3 dBi BLE 5 dBi |
| Max EIRP | 2.4 GHz: 31 dBm 5 GHz: 36 dBm |
| Power | Max power with USB/BLE, 35 W (802.3bt) 802.3at mode with USB/BT disabled 12 VDC power, 2.1 mm (.083 in) barrel connector |
| Dimensions | 235 mm x 235 mm x 42 mm (9.25 in x 9.25 in x 1.65 in) |
| Weight | 1,250 g (2.76 lbs) |
| Security | Kensington lock slot |
| LEDs | Multi-color status LEDs |
| Ambient Operating Temperature | 0ºC to 50ºC (32ºF to 122ºF) |
| Storage Temperature | -20ºC to 70ºC (-4ºF to 158ºF) Humidity 95% RH non-condensing |
| Mount Options | Wall or ceiling, T-bar with included locking bracket, ceiling tile plate |
| Certifications (Compliance) | Wi-Fi Alliance 802.11 a/b/g/n/ac/ax, PP2.0, FCC, IC, CE, EN 60601-1-2, EN 60950-1, IEC 62368-1 Safety, EN 60601-1-2 Medical, EN 61000-4-2/3/5 Immunity, EN 50121-1 Railway EMC, EN 50121-4 Railway Immunity, IEC 61373 Railway Shock & Vibration, UL 2043 Plenum, EN 62311 Human Safety/RF Exposure, WEEE & RoHS |
