TP-Link Tri-Band Omnidirectional BE11000 Indoor/Outdoor WiFi 7 Access Point
- SKU: EAP772-Outdoor
Product Information
TP-Link EAP772-Outdoor
Tri-Band Omnidirectional BE11000 Indoor/Outdoor WiFi 7 Access Point
Tri-Band Omnidirectional Coverage, 6 GHz Unlocked by AFC
Unlock the cleaner 6 GHz outdoors—powered by AFC , the EAP772-Outdoor eliminates congestion and delivers tri-band omnidirectional coverage (2.4 GHz, 5 GHz, and 6 GHz). 300m2 (3,200ft2) recommended coverage brings silky-smooth outdoor networking.
Professional Hardware Design
The EAP772-Outdoor features 1×2.5G PoE+ RJ45 port, providing high throughput for applications such as smooth live streaming and 4K video. Additionally, its dual-polarized antennas in 2.4 GHz band offer better anti-interference capability.
Industry-Leading IP68 Weatherproof Design
The fully sealed EAP772-Outdoor is completely dustproof and can be submerged in water over 1.5 meters deep for over 30 minutes,surpassing IP67. It withstands most harsh outdoor environments.
Seamless Connectivity with Mesh and Roaming
Ensures customers enjoy uninterrupted streaming when moving around by switching clients automatically to the access points with the optimal signal.
Works with Omada SDN for One-Click Setup
Omada SDN allows users to quickly set up the EAP772-Outdoor through automatic device identification and one-click adoption.
Empowering Businesses with Reliable Omada SDN Solutions
Omada’s Software-Defined Networking (SDN) solution seamlessly integrates access points (APs), managed switches, and gateways, enabling 100% centralized cloud management for a highly scalable network.
Features:
- Tri-Band Six-Stream Outdoor WiFi 7: Up to 11 Gbps.
- 6 GHz Band Unlocked by AFC: AFC enables 6 GHz band outdoor uses.
- True Tri-Band Omnidirectional Coverage: 300m2 (3,200ft2) recommended coverage*
- Professional Hardware Design: Industry-Leading IP68-Rated, 1× 2.5G PoE+ port, 2.4 GHz dual-polarized antennas.
- Easy and Quick Setup: Wall/pole mounting; Omada SDN for one-click setup
- Advanced Features: Centralized management, mesh, and seamless roaming.
Specifications
Specifications EAP772-Outdoor
| HARDWARE FEATURES | |
| Interface | 1× 2.5G Ethernet (RJ-45) Port (Support 802.3at PoE) |
| Button | Reset |
| Power Supply | • 802.3at PoE |
| Max. Power Consumption | • EU: 21.5W (for PoE) • US: 23W (for PoE) |
| Dimensions ( W x D x H ) | 9.1× 8.2 × 2.8 in (230 × 207.5 × 69.7 mm) |
| Antenna | • 2.4 GHz: 2× 4 dBi • 5 GHz: 2× 6 dBi • 6 GHz: 2× 6 dBi |
| GNSS | L1 (1575.42 MHz) receiver, supporting GPS, Galileo, GLONASS, and BeiDou signals Receive sensitivity: -164dBm (tracking) GPS antennas: Integrated 3dBi omnidirectional antennas |
| Bluetooth | BLE 5.2 |
| Weatherproof Enclosure | IP68 |
| Mounting | Pole/Wall Mounting (Kits included) |
| WIRELESS FEATURES | |
| Coverage | 300m2 (3,200ft2) Recommended Omnidirectional Coverage |
| Concurrent Clients | 250+6 |
| Wireless Standards | IEEE 802.11be/ax/ac/n/g/b/a |
| Frequency | 2.4 GHz, 5 GHz, 6 GHz |
| Signal Rate | • 802.11be: 8.6 Mbps to 5765 Mbps (MCS0-MCS13, NSS = 1 to 2 HE20/40/80/160/240/320) • 802.11ax: 8.6 Mbps to 2402 Mbps (MCS0-MCS11, NSS = 1 to 2 HE20/40/80/160) • 802.11ac: 6.5 Mbps to 2166.7 Mbps (MCS0-MCS9, NSS = 1 to 2 VHT20/40/80/160) • 802.11n: 6.5 Mbps to 300 Mbps (MCS0-MCS15, HT20/40) • 802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps • 802.11b: 1, 2, 5.5, 11 Mbps • 802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps |
| Wireless Functions | • 4k-QAM • Multiple SSlDs • OFDMA • Multiple SSIDs (Up to 16 SSIDs, 8 for each band) • Enable/Disable Wireless Radio • Automatic Channel Assignment • Transmit Power Control (Adjust Transmit Power on dBm) • QoS (WMM) • MU-MIMO • MLO • 320MHz • Omada Mesh3 • Seamless Roaming(802.11k/v/r)3 • Band Steering • Load Balance • Airtime Fairness • Beamforming • Rate Limit • Reboot Schedule • Wireless Schedule • Wireless Statistics based on SSID/AP/Client • Static IP/Dynamic lP |
| Wireless Security | • Captive Portal Authentication3 • Access Control • Wireless Mac Address Filtering • Wireless Isolation Between Clients • SSID to VLAN Mapping • Rogue AP Detection • 802.1X Support • WEP, WPA-Personal/Enterprise, WPA2-Personal/Enterprise, WPA3-Personal/Enterprise |
| Transmission Power | • CE: <20 dBm (2.4 GHz, EIRP), <28 dBm(5 GHz, band 3, EIRP) • FCC: <25 dBm (2.4 GHz), <25 dBm(5 GHz), <25 dBm(6 GHz) |
| MANAGEMENT FEATURES | |
| Omada App | Yes |
| Centralized Management | Yes, through • Omada Cloud-Based Controller • Omada Hardware Controller (OC300) • Omada Hardware Controller (OC200) • Omada Software Controller |
| Cloud Access | Yes, through • Omada Cloud-Based Controller • Omada Hardware Controller (OC300) • Omada Hardware Controller (OC200) • Omada Software Controller |
| Email Alerts | Yes |
| Management MAC Access Control | Yes |
| SNMP | v1, v2c |
| System Logging Local/Remote Syslog | Yes |
| SSH | Yes |
| Web-based Management | Yes |
| L3 Management | Yes |
| Multi-site Management | Yes |
| Management VLAN | Yes |
| Zero-Touch Provisioning | Yes. Requiring the use of Omada Cloud-Based Controller |
| OTHERS | |
| Certification | CE, FCC, RoHS |
| System Requirements | Microsoft Windows XP, Vista, Windows 7, Windows 8, Windows10, Windows11, Linux |
| Environment | • Operating Temperature: -30–70 ℃ (-22–158 ℉) • Storage Temperature: -40–70 ℃ (-40–158 ℉) • Operating Humidity: 10–90% RH non-condensing • Storage Humidity: 5–90% RH non-condensing |
