TP-Link AX3000 Outdoor/Indoor Mesh WiFi 6 AP

(0)No Reviews yet
  • SKU: HX510-Outdoor
  • Manufacturer: TP-Link
  • Data Sheet: Download
22 in stock
College Station
22 In stock

Product Information

TP-Link HX510-Outdoor

AX3000 Outdoor/Indoor Mesh WiFi 6 AP

Advanced Mesh Powered by WiFi 6

Armed with WiFi 6 technology, HX510 provides faster speeds up to 3.0 Gbps for all devices and all applications - from surfing, downloading, streaming to gaming.*

Extensive WiFi Coverage

Beamforming technology and high-performance antennas combine to adapt WiFi coverage to perfectly fit home and concentrate signal strength towards every device.

Whole Home Coverage

Empowered by EasyMesh technology, HX510 provides a strong WiFi signal in every corner of your home. Wireless connections and optional Ethernet backhaul work together to link each unit, providing even faster network speeds and truly seamless coverage. Want more coverage? Simply add another HX510 unit whenever you want.**

Seamless Roaming with One WiFi Name

All units work together to form one unified network. Your mobile device will automatically connect to the fastest unit when you move through your home, creating a truly seamless WiFi experience. ‡

More Connections, No More Buffering

Enhanced by WiFi 6, featuring with OFDMA and 160 MHz bandwidth, HX510 allows you to connect more devices simultaneously. Enjoy a more efficient network that loads faster without dragging down performance. †

2-in-1 Router and Access Point

Flexible and multi-functional, HX220 can operate either as a router or an access point. Choose whichever mode best suits your needs. More Ethernet Ports for More Options

Each unit has 3 Gigabit Ethernet ports for fast and reliable wired connections. Supports Ethernet Backhaul for more stable speeds.

Easy to Set Up and Use

You can set up your device and network in minutes, whether you prefer the powerful Aginet app or the intuitive web interface. The Aginet app allows you to manage your network from a smartphone or tablet.


  • Dual-Band Wi-Fi 6: Speeds up to 3000 Mbps—2402 Mbps on 5 GHz and 574 Mbps on 2.4 GHz.*
  • Boosted Seamless Coverage: Client Steering & Band Steering intelligently connect devices to the mesh AP with the strongest signal – ensuring connectivity regardless of physical location. A unified wireless network (SSID) is used throughout the whole home – providing a truly seamless wireless experience.‡
  • Enhanced Security: WPA3 encryption, Multi-SSID, and Parental Controls provide personalized and safer online experience.†
  • Wi-Fi CERTIFIED EasyMesh™: Experience strong, stable, and seamless wireless connections based on standard mesh technology.**
  • Easy Setup: Set up your mesh WiFi in minutes with the powerful Aginet app.
  • Easy Cloud Management: Compatible with TAUC (TP-Link Aginet Unified Cloud) to allow service providers to manage multiple devices remotely.

Specifications

Specifications HX510-Outdoor

Weight2 lbs
Dimensions (L x W x H)5 x 5 x 10 in
Interface3 × Gigabit Ports *Per Unit 1 Port supports WAN/LAN auto-sensing
ButtonReset Button WPS Button
External Power Supply12 V ⎓ 1.5 A
WIRELESS
Wireless StandardsWi-Fi 6 IEEE 802.11a/n/ac/ax 5 GHz IEEE 802.11b/g/n/ax 2.4 GHz
Frequency2.4 GHz and 5 GHz
Signal RateAX3000 5 GHz: Up to 2402 Mbps 2.4 GHz: Up to 574 Mbps
Transmit PowerFCC: <30 dBm (2.4 GHz), <30 dBm (5 GHz) CE: <20 dBm (2.4 GHz), <23 dBm (5 GHz)
Wireless SecurityWPA-PSK/WPA2-PSK/WPA3 Personal encryptions
Multi-SSID2× 5 GHz Multi-SSID 2× 2.4 GHz Multi-SSID
SOFTWARE
Quality of ServiceWMM
WAN TypeDynamic IP/Static IP/PPPoE
ManagementLocal Management, TAUC Cloud Management
Firewall SecuritySPI Firewall
ProtocolsIPv4 IPv6
Advanced FeaturesParental Controls, QoS (Quality of Service), Address Reservation, Port Forwarding, WiFi Schedule
Working ModesRouter Mode Access Point Mode
Smartphone/Tablet RequirementsAndroid 4.4 or later iOS 9.0 or later
CertificationsCE, FCC, Wi-Fi CERTIFIED 6™, Wi-Fi CERTIFIED EasyMesh™
EnvironmentOperating Temperature: 0℃–40℃ (32℉–104℉)
Storage Temperature-40℃–60℃ (-40℉–140℉)
Operating Humidity10%–90% non-condensing
Storage Humidity5%–90% non-condensing
