Cambium PTP Backhaul

ISP Supplies offers Cambium Networks Cambium PTP Backhaul for internet service providers (WISPs), wireless technicians, and other various industries

Designed for fixed outdoor applications, Cambium PTP 450 Series is ideal for enterprises and wireless service providers. It features low latency of 3 – 5 ms, flexible channel width (5, 10, and 20 MHz), 256-QAM modulation rate, and OFDM 2X2 MIMO A and B technology. It is available in 5 GHz, 3.5 GHz licensed and 3.65 GHz lightly licensed bands. The most scalable industrial-grade wireless broadband solution, Cambium PTP 450i Series features ultra-wide band radios (5 or 3 GHz), IP66/67 rated rugged metal enclosure, dynamic interference filtering, and 2X2 OFDM MIMO radio capable of up to 300 Mbps per sector.

Cambium PTP 550 Series has IP66/67 rated rugged metal enclosure for protection from solar radiation and extreme conditions, e-alignment GUI for accurate and reliable installation, independent channel bandwidth for flexibility in channel and band selection. Cambium PTP 670 Series offer more capacity, greater operational flexibility, and increased spectral efficiency. It provides 4.9 – 6.05 GHz, multi-band flexibility in a single radio and operates in the 5 – 45 MHz channel sizes. T1/E1 and fiber replacements or extensions, video surveillance backhaul, LTE/macro-cell/small-cell backhaul, network redundancy and campus connectivity are its applications.

The next-generation, all-outdoor Cambium PTP 850 Series has dual-core functionality that enables the system to operate up to 4 Gbps and deliver gigabit-plus capacity. The 850E Millimeter Wave Radio operating in the E-band (71 – 8 GHz) supports 250, 500, 1000, and 2000 MHz channels with BPSK to 512 QAM and delivers up to 10 Gbps capacity in 1+0 configuration. Cambium PTP 820 Series all outdoor single/ dual-core microwave radios support 6 – 38 GHz or 71 – 86 GHz and are capable of 1024/2048 QAM with ACM. Its accessories include single or dual-polarized parabolic antenna, optical cables, dual-tx basic radio, dual splitter kit, and RJ45 Connector for CAT6A Cable, and others. PTP 820 series high-performance 6, 11, 18, and 23 GHz antennas support telecom, enterprise, and industrial applications. The 1-7.9ft antennas have a wind survival of ups to 155 mph.

ISP Supplies is a certified distributor of Cambium Networks, offering its certified PTP Backhaul at the most inexpensive prices.
