• Home
  • ALTA Labs AP6-PRO WIFi 6 Access Point, POE+, 4x4

ALTA Labs AP6-PRO WIFi 6 Access Point, POE+, 4x4

(0)No Reviews yet
  • SKU: AP6-PRO

Product Information

ALTA Labs AP6-PRO

Alta Labs AP6-PRO WIFi 6 Access Point, POE+, 4x4

Alta Labs creates revolutionary networking technology that is driven by our proprietary software and hardware designs.

Built with Qualcomm

Provides faster, more reliable wireless connections for modern devices.

Mobile app

Monitor and manage your networks from the convenience of your mobile device.

Seamless Roaming

• Fully Automatic, 802.11k/v • With Optional 11r

Versatile Mount

• Quick Mount™ Technology for Simple Mounting • Ceiling or Wall-Mountable • Compatible with Drop-Ceilings

4096 QAM

WiFi 6 with WiFi 7 Benefits 6.3 Gbps combined WiFi Capacity

ELEVATED MANAGEMENT PLATFORM

Alta Labs cloud management platform offers seamless monitoring and configuration capabilities from any device, including desktops, laptops, and mobile devices. Our lightweight cloud technology ensures that our standard feature set remains free now and into the foreseeable future, with premium features also available. Single site and multi-site management has never been easier.

Specifications

Specifications AP6-PRO

WIFI 6Yes
BLUETOOTH FOR EASY ADOPTIONYes
CONTENT FILTERINGYes
MAX WIFI THROUGHPUT6.3 Gbps
POWERPoE+
4096-QAMYes
Dimensions190mm (7.5” ) x 125mm (4.9”) 32mm (1.25”)
Weight0.4 kg (0.9 lbs)
Enclosure MaterialTop Cover: Polycarbonate Bottom Cover: Milled Aluminum
Mount MaterialCeiling/Wall: Polycarbonate Drop Ceiling: Steel
WeatherproofingIP54
HARDWARE
Network InterfaceEthernet, WiFi, Bluetooth
Management Interface(1) GbE RJ45 Port
Button(s)Reset/Factory Reset
LEDBlue, White
Power MethodPoE+
Power SupplyPoE+ enabled network switch 48V, 0.5A PoE adapter (optional)
Supported Voltage Range42.5 - 57V DC
Maximum Power Consumption25W
Maximum Transmit Power2.4 GHz: 23 dBm @2NSS 5 GHz: 26 dBm @4NSS
MIMO2.4 GHz: 2 x 2 5 GHz: 4 x 4
Throughput Rate2.4 GHz: Up to 573 Mbps 5 GHz: Up to 5.8 Gbps
Antenna Gain2.4 GHz: Up to 3.3 dBi 5 GHz: Up to 4.8 dBi
MountingWall, ceiling, drop-ceiling, table top
Operating Temperature-30 to 60° C (-22 to 140° F)
Operating Humidity5 to 95% Noncondensing
CertificationsCE, FCC, IC
WiFi Standards801.11a/b/g/n/ac/ax WiFi4/WiFi5/WiFi6
Roaming802.11r/k/v
Wireless SecurityWPA2-PSK, WPA3-PSK, WPA-Enterprise (WPA2/WPA3)
Multi-BSSIDSupported
VLAN802.1Q
Advanced QoS802.11e
Guest Traffic IsolationSupported
Concurrent Clients300+
Zero Wait DFSYes
Intelligent WiFi SchedulingYes
Painless Hotspot SetupYes
Scale From Home to SMB to StadiumYes
Seamless Per-Client SettingsVLAN, Device Type, Rate Limit, Hotspot/Schedule Exception
SUPPORTED DATA RATES
802.11a/g6 Mbps to 54 Mbps
802.11b1 Mbps to 11 Mbps
802.11n6.5 Mbps to 600 Mbps (Up to MCS 31)

802.11ac6.5 Mbps to 3.4 Gbps (Up to MCS 9)
802.11ax

2.4 GHz: Up to 573 Mbps

5 GHz:6.5 Mbps to 5.8 Gbps

(Up to MCS 13)
