UniFi AP Comparison Chart
ISP Supplies will provide comparisons between different family members of the UniFi AC AP on the basis of various key factors such as usage, speed in GHz, 2.4GHz MiMO, range, ports, and PoE Mode.
| SKU | Use | 2.4GHz Speed | 2.4GHz MiMO | 5GHz Speed | 5GHz MiMO | Range | Ports | PoE Mode |
|---|---|---|---|---|---|---|---|---|
 UAP-AC-EDU | Indoor | 450Mbps | 3x3 | 1300Mbps | 3x3 | 400ft / 122m | (1) RJ45 GbE | 802.3at PoE+ |
 UAP‑AC‑HD | Indoor / Outdoor | 800Mbps | 4x4 | 1733Mbps | 4x4 | 400ft / 122m | (2) RJ45 GbE | 802.3at PoE+ |
 UAP-AC-IW | Indoor | 300Mbps | 2x2 | 867Mbps | 2x2 | 328ft / 100m | (3) RJ45 GbE | 802.3at PoE+ |
 UAP-AC-IW-PRO | Indoor | 450Mbps | 3x3 | 1300Mbps | 3x3 | 328ft / 100m | (3) RJ45 GbE | 802.3at PoE+ |
 UAP‑AC‑LITE | Indoor | 300Mbps | 2x2 | 867Mbps | 2x2 | 400ft / 122m | (1) RJ45 GbE | 802.3af/A PoE 24V Passive PoE |
 UAP-AC-LR | Indoor | 450Mbps | 3x3 | 867Mbps | 2x2 | 600ft / 183m | (1) RJ45 GbE | 802.3af/A PoE 24V Passive PoE |
 UAP-NanoHD | Indoor | 300Mbps | 2x2 | 1733Mbps | 4x4 | (1) RJ45 GbE | 802.3af | |
 UAP-AC-M | Indoor / Outdoor | 300Mbps | 2x2 | 867Mbps | 2x2 | 600ft / 183m | (1) RJ45 GbE | 802.3af/A PoE 24V Passive PoE |
 UAP-AC-M-PRO | Outdoor | 450Mbps | 3x3 | 1300Mbps | 3x3 | 600ft / 183m | (2) RJ45 GbE | 802.3af PoE |
 UAP-AC-PRO-E | Indoor / Outdoor | 450Mbps | 3x3 | 1300Mbps | 3x3 | 400ft / 122m | (2) RJ45 GbE | 802.3af PoE 802.3at PoE+ |
 UAP-AC-SHD | Indoor / Outdoor | 800Mbps | 4x4 | 1733Mbps | 4x4 | 164ft / 50m | (2) RJ45 GbE | 802.3at PoE+ |
