Unifi Access Point Comparison - [Complete Guide 2023]

Buying an access point that offers the best performance has become a hassle for some. But Ubiquiti Networks makes it easy for you as it provides a broad collection of Wireless Access Points, UniFi. Made of premium quality, their wireless access points deliver superior performance in several applications.

They have indoor and outdoor uses. Their applications include homes, small to medium offices, large enterprises, and high-density areas like schools, university campuses, large auditoriums, stadiums, or concert venues. Some UniFi access points have applications in secure places like banks and hospitals as well.

Ubiquiti Networks UniFi AP Types

We have various UniFi Access Points models from Ubiquiti Networks that you can choose from. To help you select an access point that would perfectly fit your requirements, we’ve classified the models into five types.

• UniFi AC
• UniFi AC MESH
• UniFi HD
• UniFi SHD
• UniFi NanoHD

These UniFi access points models are further classified into three groups based on their applications.

• Homes & Small to Medium Offices
• Enterprises & High-Density Locations
• Outdoors

UniFi AP Comparison

To compare all UniFi products on the basis of their application, we have created UniFi AP comparison charts. In these charts, we’ve compared them for speed, range, use, ports, and more. With their help, you can opt for the most suitable AP to meet your networking needs.

Unifi AP For Homes & Small to Medium-Sized Rooms/Offices

Now, look at the UniFi AP Comparison chart. From the chart, UniFi-6-Long Range, UniFi In-Wall, UniFi Lite, UniFi Long Range, and UniFi NanoHD are excellent picks for your homes and small to medium-sized businesses.

UniFi 6 Long Range – U6-LR

Ubiquiti’s U6-LR is a high-performance weatherproof wireless access point that provides powerful, wider wireless coverage to enterprise environments by leveraging advanced Wi-Fi 6 technology. It offers the best-in-class performance and reliable Wi-Fi coverage that is 2x more than UniFi AP AC LR. Plus, it gives an aggregate rate of up to 3.0 Gbps with 2.4 GHz Wi-Fi 4 (4x4 MIMO) and 5 GHz Wi-Fi 6 (4x4 MIMO and OFDMA) radios.

The AP covers a broader range. It has antennas with high-gain that are able to grab the weaker signals from your mobile device up to a longer distance.

U6-LR is a great option for mounting on the ground floor in houses with multiple floors, or when there is only room for one access point. It is IP54 rated, allowing it to be mounted in indoor as well as semi-outdoor environments. Moreover, for location-based services, it comes with a Bluetooth Low Energy Radio.

Specifications

• Indoor
• For (rooms/offices, in-house usage)
• 2.4 GHz radio rate: 600 Mbps
• 5 GHz radio rate: 2400 Mbps
• Networking interface: 10/100/1000 Ethernet Port (1)
• Power method: 48V Passive PoE; 802.at PoE
• Wi-Fi standards: 802.11 a/b/g Wi-Fi 4/Wi-Fi 5/Wi-Fi 6
• Dimensions: 48mm high, 220mm Ø
• Mounting: Wall/Ceiling
• Concurrent client capacity: +300

UniFi In-Wall – UAP-AC-IW

With the stupendous quality UAP-AC-IW, turn an Ethernet wall box into an access point. UAP-AC-IW is an in-wall access point, ideal for new and retrofit installations and doesn’t require additional wiring. It is engineered to effortlessly transform an Ethernet wall jack in a versatile dual-band 802.11ac Wi-Fi AP with two Gigabit Ethernet ports. One port provides PoE to power and connect a 802.3af device (including security camera, VoIP phone, or high-end AP) to the network.

It is capable of up to 1167 Mbps wireless speeds with a maximum range of 100m. Including rooms and offices, it is perfect for use in places using walls to install the device.

This UniFi access point offers simultaneous dual-band, 2x2 MIMO technology in the radio bands 2.4 GHz and 5 GHz, plus convenient autosensing 802.3at PoE+ support. You can power it using Ubiquiti UniFi Switch, 802.3at PoE+ compliant switch, or Ubiquiti Gigabit PoE Adapter (48V, 0.5A).

Specifications

• Indoor
• For (rooms/offices)
• 2.4 GHz radio rate: 300 Mbps
• 5 GHz radio rate: 867 Mbps
• Networking interface: 10/100/1000 Ethernet Port (3)
• Power method: 48V Passive PoE; 802.3at supported
• Wi-Fi standards: 802.11 a/b/g/n/ac
• Dimensions: 25.75mm high, 139.7mm Ø
• Mounting: 1-Gang Electrical Wall Box
• Range: 100m (328ft.)
• Concurrent client capacity: 250+

UniFi Lite - UAP-AC-Lite

UniFi Lite is a high-performance indoor Wi-Fi access point that has a sleek, cleaner design in a reduced footprint. Its size is half (160mm) as compared to the standard UniFi AP (200mm).

This AP broadcasts its signals 122m (400ft.) away which allows for greater multi-user support from further away. With dual radio, it delivers 5x better performance than the first generation UniFi AP. In addition, it uses Wave 1 technology for reaching 1.1+ Gbps throughput rate with the 2.4 GHz and 5 GHz bands.

The ultra-compact design UAP-AC-LITE AP supports 802.11ac and offers simultaneous dual-band 2x2 MIMO technology for each band. You can power it with PoE or 24V passive PoE by using a UniFi Switch. For high-speed LAN connectivity it is equipped with one GbE RJ45 port. Using the included mounting hardware, you can deploy the UniFi Enterprise Wi-Fi system to a wall or a ceiling tile very easily.

Specifications

• Indoor
• For (rooms/offices)
• 2.4 GHz radio rate: 300 Mbps
• 5 GHz radio rate: 867 Mbps
• Networking interface: 10/100/1000 Ethernet Port (1)
• Power method: 24V Passive PoE; 802.3af supported
• Wi-Fi standards: 802.11 a/b/g/n/ac
• Dimensions: 31.45mm high, 160mm Ø
• Mounting: Wall/Ceiling
• Range: 122m (400ft.)
• Concurrent client capacity: +200

UniFi Long Range – UAP-AC-LR

UAP-AC-LR is an indoor high-performance, wireless access point that uses Wave 1 technology to achieve an aggregate throughput rate of 1.2+ Gbps on its 5 and 2.4 GHz bands. It is ideal for long-range deployments and has up to 183m (600ft.), a splendidly long transmission range. This lets you establish and continue quality connectivity above large distances.

This UniFi Enterprise Wi-Fi AP features innovative antenna design for a long-range, symmetrical link coverage region. For distant client connections, UniFi AC LR's antenna gain is better than one-way, high transmit power.

The high-power UniFi Access Point supports 802.11ac. It offers simultaneous dual-band with 3x3 MIMO technology in the 2.4 GHz and 2x2 MIMO technology in the 5 GHz. You can power it with PoE or 24V passive PoE. For high-speed LAN connectivity it is equipped with one GbE RJ45 port.

Specifications

• Indoor
• For (rooms/offices)
• 2.4 GHz radio rate: 450 Mbps
• 5 GHz radio rate: 867 Mbps
• Networking interface: 10/100/1000 Ethernet Port (1)
• Port: USB 2.0 (1)
• Power method 24V Passive PoE; 802.3af supported
• Wi-Fi standards 802.11 a/b/g/n/ac
• Dimensions 43.2mm high, 175.7mm Ø
• Mounting Wall/Ceiling
• Range 183m (600ft.)
• Concurrent client capacity +200

UniFi NanoHD – UAP-NanoHD

The elegant, nano-sized UniFi NanoHD AP (Ø 16cm) is Ubiquiti’s smallest AP that is 30% smaller than UniFi AC-PRO (Ø 19.7cm). Its low-profile ceiling mount lets you smoothly integrate the AP into a wide variety of backgrounds. It comes with optional covers with camo, concrete, marble, wood, black, and fabric colors.

The 4x4 MU-MIMO AP features Four-Stream 802.11ac Wave 2 Technology that lets it support more than triple the number of users than a typical Wave 1 AP. It is fit for high-density scenarios such as theaters, where there are several clients in a small space and minimal footprint is required.

AP-NanoHD reaches 2+ Gbps throughput rate and maintains an even, reliable connection. It delivers up to 125% greater performance than a usual Wave 1 AP. It can be powered by an 802.3af PoE compliant switch. The AP can carry out complex operations that might slow down a lesser-equipped AP. With an LED provisioning ring, you can track administrator location and alerts for each device.

Specifications

• Indoor
• For high-density scenarios (theater)
• 2.4 GHz radio rate: 300 Mbps
• 5 GHz radio rate: 1733 Mbps
• Networking Interface: 10/100/1000 Ethernet port (1)
• Power Method: 802.3af PoE
• Wi-Fi Standards: 802.11a/b/g/n/ac/ac/-wave2
• Dimensions: 32.65mm high, 160mm Ø
• Mounting: Wall/Low-Profile Ceiling
• Concurrent client capacity: 200+

Unifi AP For Enterprises & High-Density Areas

Ubiquiti has terrific performance wireless access points for enterprises and high-density locations. They include UniFi HD and UniFi SHD (Secure High Density).

UniFi High Density – UAP-AC-HD

UniFi HD AP is designed in a way that covers most clients under a small area. It is perfect for high-density and critical system applications as the MU-MIMO (Multi-User, Multi-Input, Multi-Output) Technology allows it to communicate with multiple clients at once. This massively escalates multi-user throughput and overall user experience. It has a focused antenna pattern that enhances your network’s capacity and reduces interference from neighboring access points.

This UniFi Enterprise Wi-Fi AP uses Wave 2 Technology to reach a stupendous 2+ Gbps aggregate throughput rate. It has dedicated hardware offload for Guest Control, QoS, and Client Management that ensures high throughput and reduced latency.

The AP can be powered with PoE+ and is compatible with UAP-AC-PRO mounts. To support multiple connection types, it is equipped with two GbE RJ45 ports and one USB port; one of which may be bridged to another access point or to add another uplink. Additionally, it offers a secondary port for bridging.

Specifications

• Indoor and outdoor
• For high-density scenarios (concert venue, school, or outdoor fair)
• 2.4 GHz radio rate: 800 Mbps
• 5 GHz radio rate: 1733 Mbps
• Networking Interface: 10/100/1000 Ethernet ports (2)
• Port: USB Type C (1)
• Power Method: 802.3at PoE+
• Wi-Fi Standards: 802.11a/b/g/n/ac/ac-wave2
• Dimensions: 48.1mm high, 220mm Ø
• Mounting: Wall/Ceiling
• Range: 122m (400ft.)
• Concurrent client capacity: 1000+

UniFi Secure High Density – UAP-AC-SHD

Wave 2 802.11ac high-density, 4x4 MU-MIMO UniFi SHD AP features dedicated security radio and persistent threat management. Its airView tool provides real-time visibility into your RF spectrum. While, the airTime tool shows and examines how APs utilize channels in real-time.

The built-in security and monitoring radios of our UniFi Secure High Density access point offer visibility into channel planning, site performance, and local interferers. This allows the integrator to correctly evaluate performance and swiftly respond to security threat landscapes and changing interference. The UniFi access point can deliver 125% (max.) higher performance than the typical Wave 1 APs.

This UniFi Enterprise Wi-Fi AP uses Wave 2 technology to reach amazing 2.5 Gbps aggregate throughput rate with its 2.4 GHz (4x4 MIMO) and 5 GHz (4x4 MU-MIMO) bands. It can be powered with PoE+. To support multiple connection types, it is equipped with two GbE RJ45 ports and one USB port.

Specifications

• Indoor and outdoor
• For high-density scenarios (concert venue or outdoor fair)
• 2.4 GHz radio rate: 800 Mbps
• 5 GHz radio rate: 1733 Mbps
• Networking Interface: 10/100/1000 Ethernet ports (2)
• Port: USB Type C (1)
• Power Method: 802.3at PoE+
• Wi-Fi Standards: 802.11a/b/g/n/ac/ac-wave2
• Dimensions: 48.1mm high, 220mm Ø
• Mounting: Wall/Ceiling (Kits included)
• Range: 50m (164 ft.)
• Concurrent client capacity: 1000+

UniFi AP For Outdoors

We also have Ubiquiti APs that are best for covering outdoor areas. They include UniFi Mesh and UniFi Mesh Pro.

UniFi MESH – UAP-AC-M

The high-performance wide area UAP-AC-M features Wi-Fi 802.11ac with Plug & Play Mesh Technology. It has adjustable dual-band omni antennas and uses the same antenna connector technology as airTime antennas. If you have a lot of APs and clients in a meeting room or event center, you can use a 5 GHz omni antenna1. For broad outdoor coverage, you can use a 5GHz sector antenna (wide beam in azimuth, narrow beam in elevation).

UniFi AC Mesh can be used indoors or outdoors as they have weather-resistant enclosure. You can use it in large outdoor areas such as a park with minimal infrastructure, university/industrial campuses, corporate buildings, internet cafes, dorm or residence, and hotels.

The AP offers simultaneous dual-band operation with 2x2 MIMO on both radio bands, 2.4GHz and 5GHz, for up to 1167Mbps breakthrough speeds. It can be powered by UniFi PoE Switch, 802.3af Alternative Switch, or Ubiquiti Gigabit PoE adapter.

Specifications

• Indoor and outdoor
• For high-density scenarios (conference hall, street fair, music festival, event center, park)
• 2.4 GHz radio rate: 300 Mbps
• 5 GHz radio rate: 867 Mbps
• Networking Interface: 10/100/1000 Ethernet Port (1)
• Power Method: 24V passive PoE; 802.3af PoE Alternative A
• Wi-Fi Standards: 802.11 a/b/g/n/ac
• Dimensions: 34.4mm high, 353mm Ø
• Mounting: Wall/Pole/Fast-Mount
• Range: 183m (600ft.)
• Concurrent client capacity: 250+

UniFi MESH PRO – UAP-AC-M-PRO

The outdoor-ready, high-performance wide-area Wi-Fi with Plug and Play Mesh technology is engineered to give exceptional 360-degree coverage with up to 183m symmetrical long-range communications. With built-in 3 omni-directional antennas, it delivers maximum coverage in outdoors and act as a network extender. In addition, its enclosure is designed to withstand any element, making it suitable for outdoor deployments.

UniFi Mesh Pro is great for covering the park and quad on a university campus. It has applications in university/industrial campuses, corporate buildings, internet cafes, dorm or residence, and hotels.

This wireless access point offers simultaneous, dual-band 3x3 MIMO technology on both radio bands, 2.4 GHz and 5 GHz, for up to 1750Mbps. You can power it via PoE. To support multiple high-speed LAN connections, it comes with two GbE RJ45 ports; one for data and PoE, and the other for bridging.

Specifications

• Outdoor
• For high-density scenarios (conference hall, street fair, music festival, event center, park)
• 2.4 GHz radio rate: 450 Mbps
• 5 GHz radio rate: 1300 Mbps
• Networking Interface: 10/100/1000 Ethernet Port (2)
• Power Method: 802.3af PoE
• Wi-Fi Standards: 802.11 a/b/g/n/ac
• Dimensions: 60.2mm high, 343.2mm Ø
• Mounting: Wall/Pole
• Range: 183m (600ft.)
• Concurrent client capacity: 250+

All UniFi APs are available in single and five-packs, except NanoHD AP – It is available in three packs. And all APs, except for the UAP-IW, include wall/ceiling mount kits and PoE adapter. The APs seamlessly integrate into any environment. UniFi HD, UniFi SHD, and UniFi NanoHD carry out complex operations that might slow down a lesser-equipped AP. The UniFi Enterprise Wi-Fi APs come with many great features such as unique LED, compact form factor, and versatile mounting options. With LED provisioning ring, you can track administrator location and alerts for each device. Apart from that, their compact design allows a cost-effective combination of performance and value.

A Wave 2 AP can offer up to 33% higher performance than a Wave 1 AP. Both Wave 1 and Wave 2 Access Points offer 28 independent (non-overlapping) channels; three for the 2.4 GHz band and twenty-five for the 5 GHz band.

Closing Thoughts

This comparison of all UniFi products will aid you in opting for the perfectly suitable Ubiquiti access point for your network. Nevertheless, picking a wireless access point out that offers the best performance depends on what your needs are!
