Cambium XV2-22H Wall Plate Dual radio WiFi 6 AP, 2x2, 4 x GbE, 48V PoE out, BLE/Zigbee (US Version)

(0)No Reviews yet
  • SKU: XV2-22H0A00-US
  • Manufacturer: Cambium Networks
  • Data Sheet: Download
1 in stock
College Station
1 In stock

Product Information

Cambium Networks XV2-22H0A00-US

XV2-22H Wall Plate Dual radio WiFi 6 AP, 2x2, 4 x GbE, 48V PoE out, BLE/Zigbee (US Version)

Features:

  • Dimensions: 335mm x 280mm x 230mm carton size
  • HTS code: 8517.62.0090 HTS code
  • Items:10 items per carton
  • Wi-Fi 6 (802.11ax)
  • Up to 2976 Mb/s Throughput
  • 2.4 GHz / 5 GHz (Dual-Band)
  • 5.56 dBi Internal Antennas
  • 1 x Gigabit Ethernet PoE+ Uplink
  • 3 x Gigabit Ethernet PoE Ports
  • 2 x RJ45 Passthrough
  • Up to 128 Clients
  • Includes Junction Box Mounting Kit
  • Local and Cloud Management

Specifications

Specifications XV2-22H0A00-US

Wireless
Wi-FiWi-Fi 6 (802.11ax)
MU-MIMO Support2 x 2
Antenna Gain4.4 to 5.5 dBi
Supported Protocols
Auto-MDIX/MDI
IPv4
IPv6
RADIUS
SNMPv1
SNMPv2c
SNMPv3
Antenna PlacementInternal
BluetoothNone
Throughput2976 Mb/s Total
5 GHz: 2402 Mb/s
2.4 GHz: 574 Mb/s
Interface
Inputs/Outputs1 x 10/100/1000 Mb/s Gigabit Ethernet (RJ45) (Uplink) PoE+
2 x 10/100/1000 Mb/s Gigabit Ethernet (RJ45) PoE
2 x Ethernet (RJ45) (Pass-Through)
Security
Guest Network SupportYes
Wireless SecurityWEP, WPA, WPA-PSK, WPA2, WPA2-Enterprise, WPA3
Lock SlotYes, Kensington
Management
Operation ModesAccess Point
Supported Clients128
Max SSIDs Supported16
Mobile App CompatibleYes
Hardware
Supported IEEE Standards802.11a, 802.11ac, 802.11ax, 802.11b, 802.11e, 802.11g, 802.11n, 802.11r, 802.11u, 802.1x, 802.3af, 802.3at
Environmental
Operating Temperature32 to 104°F / 0 to 40°C
Storage Temperature-40 to 158°F / -40 to 70°C
Operating Humidity95% (Non-Condensing)
IP RatingNone
Dimensions (LxWxH)6.3 x 4.1 x 1.3" / 160 x 105 x 32 mm
Weight0.9 lb / 417 g
