Mean Well 48Vdc DIN Rail Power Supply UL 508 48V 10A
- SKU: NDR-480-48
- Manufacturer: Mean Well
- Data Sheet: Download
Product Information
Mean Well NDR-480-48
48Vdc DIN Rail Power Supply UL 508 48V 10A
NDR-480 is one economical slim 480W Din rail power supply series, adapt to be installed on TS-35/7.5 or TS-35/15 mounting rails. The body is designed 85.5mm in width, which allows space saving inside the cabinets. The entire series adopts the full range AC input f rom 90 VAC to 264 VAC and conforms to BS EN/EN61000-3-2, the norm the European Union regulates for harmonic current.
NDR-480 is designed with metal housing that enhances the unit's power dissipation. With working efficiency up to 92.5%, the entire series can operate at the ambient temperature between -20℃ and 70℃ under air convection. It is equipped with constant current mode for over-load protection, fitting various inductive or capacitive applications. The complete protection functions and relevant certificates for industrial control apparatus (UL508, TUV BS EN/EN62368-1, and etc.) make NDR-480 a very competitive power supply solution for industrial applications.
Features:
- Universal AC input / Full range.
- Built-in active PFC function.
- Protections: Short circuit / Overload / Over voltage/ Over temperature.
- Cooling by free air convection.
- Can be installed on DIN rail TS-35/7.5 or 15
- UL 508 (industrial control equipment) approved.
- BS EN/EN61000-6-2(BS EN/EN50082-2) industrial immunity level.
- 100% full load burn-in test.
- 3 years warranty.
Applications:
- Industrial control system.
- Factory automation.
- Electro-mechanical apparatus.
Specifications
Specifications NDR-480-48
| DC VOLTAGE | 48V |
| RATED CURRENT | 10A |
| CURRENT RANGE | 0 ~ 10A |
| RATED POWER | 480W |
| RIPPLE & NOISE (max.) Note.2 | 150mVp-p |
| OUTPUT | |
| VOLTAGE ADJ. RANGE | 48 ~ 55V |
| VOLTAGE TOLERANCE Note.3 | ±1.0% |
| LINE REGULATION | ±0.5% |
| LOAD REGULATION | ±1.0% |
| SETUP, RISE TIME | 1500ms, 100ms/230VAC 3000ms, 100ms/115VAC at full load |
| HOLD UP TIME (Typ.) | 16ms/230VAC 16ms/115VAC at full load |
| INPUT | |
| VOLTAGE RANGE Note.4 | 90 ~ 264VAC 127 ~ 370VDC |
| FREQUENCY RANGE | 47 ~ 63Hz |
| POWER FACTOR (Typ.) | PF>0.98/115VAC, PF>0.94/230VAC at full load |
| EFFICIENCY (Typ.) | 0.925 |
| AC CURRENT (Typ.) | 4.8A/115VAC 2.4A/230VAC |
| INRUSH CURRENT (Typ.) | 20A/115VAC 35A/230VAC |
| LEAKAGE CURRENT | <2mA / 240VAC |
| PROTECTION | |
| OVERLOAD | 105 ~ 130% rated output power |
| Protection type : Constant current limiting, unit will shut down after 3 sec., re-power on to recover | |
| OVER VOLTAGE | 56 ~ 65V |
| Protection type : Shut down o/p voltage, re-power on to recover | |
| OVER TEMPERATURE | Shut down o/p voltage, recovers automatically after temperature goes down |
| ENVIRONMENT | |
| WORKING TEMP. | -20 ~ +70℃ (Refer to "Derating Curve") |
| WORKING HUMIDITY | 20 ~ 95% RH non-condensing |
| STORAGE TEMP., HUMIDITY | -40 ~ +85℃, 10 ~ 95% RH |
| TEMP. COEFFICIENT | ±0.03%/℃ (0 ~ 50℃) |
| VIBRATION | Component:10 ~ 500Hz, 2G 10min./1cycle, 60min. each along X, Y, Z axes; Mounting: Compliance to IEC60068-2-6 |
| SAFETY & EMC | |
| SAFETY STANDARDS | UL508, TUV BS EN/EN62368-1, EAC TP TC 004 , BSMI CNS14336-1 approved;(meet BS EN/EN60204-1) |
| WITHSTAND VOLTAGE | I/P-O/P:3KVAC I/P-FG:2KVAC O/P-FG:0.5KVAC |
| ISOLATION RESISTANCE | I/P-O/P, I/P-FG, O/P-FG:>100M Ohms / 500VDC / 25℃/ 70% RH |
| EMC EMISSION | Compliance to BS EN/EN55032 (CISPR32),BS EN/EN61204-3 Class B,BS EN/EN61000-3-2,-3,EAC TP TC 020,CNS13438 Class B |
| EMC IMMUNITY | Compliance to BS EN/EN61000-4-2,3,4,5,6,8,11,BS EN/EN55024,BS EN/EN61000-6-2 (BS EN/EN50082-2),BS EN/EN61204-3, heavy industry level, criteria A, EAC TP TC 020 |
| MTBF | 146.8K hrs min. MIL-HDBK-217F (25℃) |
| DIMENSION | 85.5*125.2*128.5mm (W*H*D) 3.36 x 4.92 x 5.05 inches |
| PACKING | 1.5Kg; 8pcs/13Kg/0.9CUFT (3.30 lbs) |
