KP Performance Two 3 GHz 65° ±45 Degree Slant 18dBi in One Shell Orientated as 90° Sectors
US$602.30 US$634.00
- SKU: KP-3S3S-65SA
- Manufacturer: KP Performance
- Data Sheet: Download
Product Information
KP Performance KP-3S3S-65SA
3 GHz ±45 Deg. Slant + 3 GHz ±45 Deg. Slant Combo 65 Deg. Sector Antenna Side Angle Alignment (Two Sectors In One Shell That Cover 180 Deg.)
The KP-3S3S-65SA is a 4-port sector antenna that features two 3 GHz antennas in one radome. Two 3 GHz ±45° slant polarization antennas are integrated into a single radome enclosure with each internal antenna fed via its own individual connectors. The two 65° sectors in a single radome are angled to cover 180° - two ports point to -45° and two ports point to +45°. Using two of the KP-3S3S-65SA antennas is a direct replacement for using 4 single 65° sectors to cover 360° in a frequency-reuse two scenario (ABAB). This 3 GHz dual sector antenna simultaneously reduces tower space, maximizes coverage and minimizes interference with its high gain and slant dual polarization performance.The KP-3S3S-65SA sector antenna offers 17.0 dBi gain and a front-back ratio as high as 35 dB. This sector antenna utilizes four 7/16 DIN connectors and operates in the popular frequency range of 3.3 GHz to 3.8 GHz and delivers VSWR of 1.7:1. Cables not included. To purchase compatible 7/16 DIN to Type-N cables for this antenna.
Features:
- 4-port sector antenna, 3300-3800 MHz, 65° HPBW, 3.5° fixed electrical downtilt
- Two 65°sectors in a single radome cover 180°
- Two antennas provide 360° coverage and reduce tower space
- High gain and slant dual polarization
- Simultaneously maximize coverage and minimize interference
Specifications
Specifications KP-3S3S-65SA
Frequency Range: | 3.3 GHz to 3.8 GHz |
Polarization Type: | 45 Deg. Slant |
Gain: | 17 dBi |
Vertical Beamwidth: | 7° |
Horizontal Beamwidth: | 65° |
Electrical Downtilt: | 3.5° |
F/B Ratio: | 30 dB |
VSWR: | 1.7:1 |
Cross Polar Ratio: | 25 dB |
Port Isolation: | 25 dB |
Connector Type: | 4 x 7/16 DIN Female |
