MikroTik RouterBOARD RBD53iG-5HacD2HnD-US (US Version)

hAP ac³ Wireless Dual-band Router 5 Gigabit Ethernet Ports 716MHz CPU 256MB RAM

hAP ac³ - the new standard of home access points

Building upon our successful hAP heritage, the new hAP ac3 is faster and has powerful external antennas for the best WiFi coverage. In comparison with hAP ac2, hAP ac3 brings also twice as much RAM (256MB), PoE-out on port#5 and 128MB NAND for more storage.

This Wireless Dual-band Router 5 Gigabit Ethernet ports, 256 MB of RAM and quad-core CPU, hAP ac³ can satisfy even the biggest and most demanding households. With PoE support, it can power or be powered by other devices. There is a 128 MB NAND and a full-size USB port that you can use to add extra storage. The new enclosure allows mounting the device vertically or horizontally. A wall mount set is also included.

Reliable connection for all your devices

Stop sharing the frequency with all your neighbors! Strong dual-chain dual-band 2.4/5 GHz wireless for concurrent coverage will solve most interference issues in a crowded environment. This is a must-have these days! You can use the 2.4 GHz channel for older devices and the 5 GHz channel for everything else, since this frequency is less cluttered.

RouterOS – extreme versatility

Run a secure VPN from the office directly to your home, enable parental control, Quality of Service (traffic prioritization for certain needs, such as streaming), specific firewall rules, IPsec hardware acceleration, VLAN, DHCP, e-mail or SMS notifications, and so on. With RouterOS scripting you can automate a lot:

  • modify queues based on bandwidth usage;
  • complex trigger notifications, such as “Your bandwidth has reached X for Y minutes!”
  • backups and setup of additional devices, and so much more!

Features:

  • 5x Gigabit Ethernet portsv
  • Quad-core CPUv
  • PoE-in/PoE-out
  • 128 MB NAND
  • Extreme versatility with the powerful RouterOS
  • Powerful external high gain antennas (3 – 5.5 dBi)
  • iOS/Android app for quick and easy configuration
  • Strong dual-chain dualband 2.4/5 GHz Wireless

Specifications

Specifications RBD53iG-5HacD2HnD-US

CPU 4 core IPQ-4019 716 MHz
Number of 1GbE ports 5
Number of 1GbE ports with PoE-out 1
Size of RAM 256 MB
Size of NAND 128 MB
Wireless 2.4 GHz 802.11 b/g/n dual-chain, 5 GHz 802.11 a/n/ac dual-chain
Wireless regulations Specific frequency range and power will be limited by country regulations
Wireless antenna max gain 2.4 GHz (3 dBi), 5 GHz (5.5 dBi)
Antenna beam width 360°
Dimensions 251 x 129 x 39 mm
Operating system RouterOS, License level 4
USB port 1 USB port type A
Operating temparature -40°C to +70°C
Powering
PoE-in Passive PoE
PoE-out * Passive PoE
Supported input voltage DC jack (12 - 28 V) PoE-in (18-28 V)
Power adapter nominal voltage 24 V
Power adapter nominal current 1.5 A
Max out per port output (input < 30 V) 0.5 A
Max power consumption without attachments 12 W
Max power consumption 30 W
Certification & Approvals
Certification CE, FCC, IC

Wireless Spec
Rate (2.4 GHz) Tx (dBm) Rx (dBm)
1Mbit/s 25 -100
11Mbit/s 25 -94
6Mbit/s 26 -96
54Mbit/s 23 -78
MCS0 26 -96
MCS7 22 -73
Rate (5 GHz) Tx (dBm) Rx (dBm)
6MBit/s 26 -96
54MBit/s 22 -80
MCS0 26 -96
MCS7 21 -75
MCS9 19 -70
