ITELITE Radio Antenna 2.4 GHz 19 dBi H/V-Pol

(0)No Reviews yet
  • SKU: SRA2419
  • Manufacturer: ITElite
  • Data Sheet: Download

Out of Stock

Direct Ship Item

Product Information

ITELITE SRA2419 Radio Antenna 2.4 GHz 19 dBi H/V-Pol

Antenna with integrated enclosure working in 2.4 GHz band with 19 dBi gain that can be mounted for horizontal or vertical polarization. The range includes weatherproof outdoor enclosure with panel antenna and enough compartment for RouterBoard or any other electronic equipment. Enclosure is furnished with special RJ-45 waterproof ethernet connector with an easy connection to Internet Network and PoE. Perfectly designed for operation under severe weather conditions. Proper materials allow operation in the salty water environment without corrosion. High quality construction of pole mounting elements guarantee easy elevation and easy tilt down as well as rock-stable operation. It can be used as customer premise equipment and also as a base stations. Inside the enclosure there are suitable posts for all Mikrotik Routerboards, mounting for Ubiquiti Rocket and for other radios.


Specifications SRA2419

Electrical Properties
Frequency2.4 - 2.4 GHz
Polarizationhorizontal or vertical
Beamwidth deg horizontal20°
Beamwidth deg vertical28°
Impedance50 ohm
Front to back ratio> 35 dB
Lightning protectionDC ground
Enclosure Properties
MaterialUV protected
Min temperature-40°C / -40°F
Max temperature80°C / 176°F
Mechanical Properties
Compatible withRB411, RB433 and RB600 series
Input ConnectorUFL, MMCX, RPSMA
Enclosure ConnectorWaterproof Ethernet Connector RJ45 (or cable gland optional)
Outside Dimensions385x385x80mm / 15.15x15.15x3.15"
Weight2.4kg / 5.3lbs
