ALGcom Extreme Full band Parabolic Antenna UHPX 4.9-6.425GHz 30 dBi 0.6m
US$539.00
- SKU: UHPX-5800-30-06-DP-RPSMA
- Manufacturer: ALGcom
- Data Sheet: Download
Product Information
ALGcom UHPX-5800-30-06-DP
Extreme Full band Parabolic Antenna UHPX 4.9-6.425GHz 30 dBi 0.6m
Features:
- Incredible bandwidth: 4.9-6.425 GHz
- Point to Point antenna with Ultra High Performance and Extreme noise rejection
- Outstanding VSWR and Port-to-port isolation
Specifications
Specifications UHPX-5800-30-06-DP
| CROSS POLARIZATION INSULATION | > 30dB |
| DIAMETER | 0.6 | 2ft |
| PTP DISTANCE | Up to 30 Km |
| POLARIZATION | Double (V and H) or Slant (+/- 45º) |
| GAIN | 30.5dBi |
| CONNECTION | SMA female reverse |
| POWER HALF ANGLE | 5,8º |
| WEIGHT | 12.5 Kg |
| FREQUENCY | 4.9-6.425Ghz |
| FRONT-TO-BACK RATIO | >55 dB |
| LINK | Point-to-Point |
| WARRANTY | 3 Years |
