APC Back-UPS, 390 Watts / 650 VA, Input 120V / Output 120V, Interface Port USB
- SKU: BE650G1
- Manufacturer: APC
- Data Sheet: Download
Product Information
APC Back-UPS, 390 Watts / 650 VA, Input 120V / Output 120V, Interface Port USB
The most popular desktop UPS in the world!
APC's Back-UPS® ES series is now "greener" than ever. The ES 650 utilizes an ultra-efficient design that consumes less power during normal operation than any other battery backup in its class, saving you money on your electricity bill. It's also RoHS compliant, which means its manufacture and ultimate disposal is easier on the environment. Even the packaging has been carefully selected to minimize energy use in it's creation, and to maximize the use of recycled materials. Coupled with all the standard features of the Back-UPS ES series, the ES 650 is the best value for home and home office computers.
Key Features
- Battery failure notification
- Battery replacement without tools
- Disconnected battery notification
- Intelligent battery management
- LED status indicators
- Replace Battery LED
- USB connectivity
- User-replaceable batteries
Specifications
Output | |
Output Power Capacity | 390 Watts / 650 VA |
Max Configurable Power | 390 Watts / 650 VA |
Nominal Output Voltage | 120V |
Output Frequency (sync to mains) | 60 Hz |
Waveform Type | Stepped approximation to a sinewave |
Output Connections | (4) NEMA 5-15R (Battery Backup), (4) NEMA 5-15R (Surge Protection) |
Required Output Current Protection | 15A |
Input | |
Nominal Input Voltage | 120V |
Input Frequency | 50/60 Hz |
Input Connections | NEMA 5-15P |
Cord Length | 6 feet (1.83 meters) |
Input voltage range for main operations | 88 - 139V |
Maximum Input Current | 12A |
Input Breaker Capacity | 15A |
Batteries & Runtime | |
Battery Type | Maintenance-free sealed Lead-Acid battery with suspended electrolyte: leakproof |
Typical recharge time | 24 hour(s) |
Replacement battery cartridge | RBC17 |
RBC™ Quantity | 1 |
Communications & Management | |
Interface Port(s) | USB |
Control Panel | LED status display with On Line : On Battery : Replace Battery and Building Wiring Fault |
Audible Alarm | Alarm when on battery : distinctive low battery alarm : overload continuous tone alarm |
Surge Protection and Filtering | |
Surge Energy Rating | 365 Joules |
Filtering | Full time multi-pole noise filtering : 5% IEEE surge let-through : zero clamping response time : meets UL 1449 |
Dataline Protection | RJ-45 Modem/Fax/DSL/10-100 Base-T protection,Co-axial Video / Cable protection |
Physical | |
Maximum Height | 3.40 inches (86 mm) |
Maximum Width | 7.10 inches (180 mm) |
Maximum Depth | 11.20 inches (284 mm) |
Net Weight | 13.64 lbs. (6.20 kg) |
Color | Black |
SCC Codes | 1073130425652 3 |
Environmental | |
Operating Environment | 32 - 104°F (0 - 40°C) |
Operating Relative Humidity | 5 - 95% |
Operating Elevation | 0-10000 feet (0-3000 meters) |
Storage Temperature | 5 - 113°F (-15 - 45°C) |
Storage Relative Humidity | 5 - 95% |
Storage Elevation | 0-50000 feet (0-15000 meters) |
Audible noise at 1 meter from surface of unit | 45.00 dBA |
Online Thermal Dissipation | 15.00 BTU/hr |
Conformance | |
Regulatory Approvals | CSA C22.2 No. 107.1,FCC Part 15 Class B,FCC Part 68,NOM,TUV-C,UL 1778 |
Standard Warranty | 3 years repair or replace |
Environmental Compliance | RoHS,REACH: Contains No SVHCs |
