APC Smart-UPS, Lithium-Ion, Short Depth 750VA, 120V with SmartConnect Port

  • SKU: SMTL750RM2UC
  • Manufacturer: APC
  • Data Sheet: Download
  • Availability: 1 In Stock    (updated live)
US$‎1,050.00

Specifications SMTL750RM2UC

Output
Output power capacity 600 Watts / 750VA
Max Configurable Power (Watts) 600 Watts / 750VA
Nominal Output Voltage 120V
Output Voltage Distortion Less than 5 %
Output Frequency (sync to mains) 50/60 Hz +/- 3 Hz Sync to mains
Topology Line interactive
Waveform type Sine wave
Output Connections (6) NEMA 5-15R
Transfer Time 6 ms typical : 10 ms maximum
Input
Nominal Input Voltage 120V
Input frequency 50/60 Hz +/- 3 Hz Auto-sensing
Input Connections NEMA 5-15P
Cord Length 8ft (2.4meters)
Input voltage range for main operations 75 - 154 Adjustable, 82 - 144V
Number of Power Cords 1
Batteries & Runtime
Battery type Li-Ion (Lithium-Ion)
Typical recharge time 3hour(s)
Expected Battery Life (years) 5 - 10
Battery Charge Power (Watts) 50 Watts
Battery Volt-Amp-Hour Capacity 150
Communications & Management
Interface Port(s) RJ-45 Serial, SmartSlot, USB
Control panel Multifunction LCD status and control console
Audible Alarm Alarm when on battery : distinctive low battery alarm : configurable delays
Surge Protection and Filtering
Surge energy rating 680Joules
Filtering Full time multi-pole noise filtering : 0.3% IEEE surge let-through : zero clamping response time : meets UL 1449
Physical
Maximum Height 3.4inches (86MM, 8.6CM)
Maximum Width 17.2inches (438MM, 43.8CM)
Maximum Depth 12.5inches (318MM, 0.0CM)
Rack Height 2U
Net Weight 34.0lbs. (15.42KG)
Shipping weight 39.0lbs. (17.69KG)
Shipping Height 9.0inches (229MM, 22.9CM)
Shipping Width 23.0inches (584MM, 58.4CM)
Shipping Depth 18.6inches (472MM, 47.2CM)
Color Black
Units per Pallet 16.0
Environmental
Operating Temperature 32 - 104 °F (0 - 40 °C)
Operating Relative Humidity 0 - 95 (Non-condensing) %
Operating Elevation 0 - 10000ft (0 - 3048meters)
Storage Temperature -40 - 35 °C
Storage Elevation 0 - 25000ft (0 - 7620meters)
Audible noise at 1 meter from surface of unit41.0dBA
Online thermal dissipation 70.0BTU/hr
Conformance
Approvals CSA C22.2 No 107.3, FCC part 15 class A, NOM, UL 1778, UL 1973
Equipment protection policy Lifetime : $150000
Standard warranty 5 year repair or replace

APC SMTL750RM2UC

Smart-UPS, Lithium-Ion, Short Depth 750VA, 120V with SmartConnect Port

Intelligent and efficient network power protection from entry level to scaleable runtime. Ideal UPS for servers, point-of-sale, routers, switches, hubs and other network devices.

Features:

  • Cold-start capable Provides temporary battery power when the utility power is out.
  • Energy meter Provides actual kilowatt hours of usage for energy conscious users.
  • Green mode Patent-pending operating mode that bypasses unused electrical components in good power conditions to achieve very high operating efficiency without sacrificing any protection.
  • High online efficiency Reduces utility costs, generates less heat.
  • Lithium-ion battery Lithium-ion batteries provide twice the service life of a typical lead acid battery and are small, light and environmentally friendly.
  • Predictive replace battery date Dynamically provides the month and year when battery replacement is recommended to aide in long term maintenance planning.
  • Pure sine wave output on battery Simulates utility power to provide the highest degree of compatibility for active PFC (power factor corrected) servers and sensitive electronics.
  • Short-depth rack compatibility Compact design fits comfortably in short-depth rack applications.
  • Single switched outlet group Single outlet group that may be controlled separately from the UPS for discrete reboot of hung devices, sequenced on/off and non-critical load shedding.
  • SmartConnect Innovative, easy to use remote monitoring feature that provides automatic notifications, firmware updates, and advanced support services.
  • SmartSlot Customize UPS capabilities with management cards.
  • Temperature-compensated battery charging Prolongs battery life by regulating the charge voltage according to battery temperature.

Smart-UPS Features & Benefits

Save time with easy and convenient remote accessibility Network manageable via serial, USB or optional ethernet. Includes Powerchute® Business Edition Software for convenient monitoring and control, safe operating system shutdown and innovative energy management capabilities.

Smarter productivity with ability to tailor to your specific application needs Intuitive LCD interface provides clear information with the ability to configure the UPS locally with easy to use navigation keys. Over 15 different programmable settings including switched outlet group control allow for application specific settings, thresholds and notifications.

Low operating and maintenance costs with high efficiency, proven reliability and intelligent battery management Patented green operating mode achieves efficiencies over 97%. Smart-ups was the first network UPS to be Energy Star certified. Intelligent battery management, pioneered by APC, maximizes battery performance and life through intelligent, precision temperature compensated charging. Dynamic battery replacement date indicator and automatic self tests insure battery reliability and warn in advance of needing replacement. Convenient, easy to connect, hot-swappable battery modules provide battery replacement without powering down. Designed and manufactured by APC for over 23 years, Smart-UPS is the world’s most trusted network UPS with over 25 million units sold.

Peace of mind that comes with full equipment compatibility and reliability of a leader Provides pure sine wave output which is recommended by server manufacturers using active power factor corrected (PFC) power supplies. Safety agency tested and approved means that you can deploy Smart-UPS with confidence that they meet or exceed the industry’s most rigorous standards.

Avoids costly power problems by keeping your IT equipment and data safe and available Network grade power conditioning protects from damaging surges and disruptive noise. Solid state automatic voltage regulation boosts low input voltage up to 30% and trims high voltage up to 12% without battery operation. Reliable battery back-up capacity to power through outages or gracefully shutdown systems

Safety

  • Safety-agency approved Ensures the product has been tested and approved to work safely with the connected service provider equipment and within the specified environment.

Manageability

  • USB connectivity Provides management of the UPS via a USB port (not available on all models).
  • Serial connectivity Provides management of the UPS via a serial port.
  • Audible alarms Provides notification of changing utility power and UPS conditions.
  • LED status indicators Quickly understand unit and power status with visual indicators.
  • Network manageable Provides remote power management of the UPS over the network.

Adaptability

  • Adjustable voltage sensitivity Provides the ability to adapt the UPS for optimal performance in specific power environments or generator applications.
  • Adjustable voltage-transfer points Maximizes useful battery life by widening the input voltage window or tightening the output voltage regulation.

Availability

  • Intelligent battery management Maximizes battery performance, life, and reliability through intelligent, precision charging.
  • Power conditioning Protects connected loads from surges, spikes, lightning, and other power disturbances.
  • Disconnected battery notification Warns when a battery is not available to provide backup power.
  • Temperature-compensated battery charging Prolongs battery life by regulating the charge voltage according to battery temperature.
  • Boost and Trim Automatic Voltage Regulation (AVR) Gives higher application availability by correcting low and high voltage conditions without using the battery (not available on all models).
  • Automatic self-test Periodic battery self-test ensures early detection of a battery that needs to be replaced.
  • Automatic restart of loads after UPS shutdown Automatically starts up the connected equipment upon the return of utility power.

Serviceability

  • User-replaceable batteries Increases availability by allowing a trained user to perform upgrades and replacements of the batteries reducing Mean Time to Repair (MTTR)v
  • Resettable circuit breakers Enables a quick recovery from overload events.
  • Hot-swappable batteries Ensures clean, uninterrupted power to protected equipment while batteries are being replaced
  • Predictive failure notification. Provides early-warning fault analysis ensuring proactive component replacement.
  • Battery failure notification Provides early-warning fault analysis on batteries enabling timely preventive maintenance
