Cambium 60GHz cnWave V1000 Client Node with US cord

  • SKU: C600500C001A
  • Manufacturer: Cambium Networks
  • Data Sheet: Download
  • Availability: 10 In Stock    (updated live)
US$‎278.43

Specifications C600500C001A

Client Node Model V1000
Maximum Throughput in DL or UL 1 Gbps
Maximum EIRP 38 dBm
Spectrum
Frequency Range 57 to 66 GHz in a single SKU
Channel Width 2.16 GHz, 4.32 GHz*
Carrier Bonding* Up to 2 adjacent channels
Mode of Operation PMP or Mesh, PTP
Interface
Channel Access TDMA/TDD
Ethernet Interface 1 x 100/1000/10G BaseT with PoE In, 1 x 100/1000 BaseT with 802.3at PoE Out, 1 x SFP+
Ethernet
Protocol Supported IPv4, IPv6
Network Management cnMaestro, HTTP, HTTPS, SNMP v2c & v3
MTU 4,000 bytes
VLAN* 802.1ad (QinQ), 802.1Q with 802.1p priority
QoS* 4 Level QoS, DSCP and VLAN Tag
Security
Encryption 128-bit AES
Firmware Security Signed Firmware Images
Performance
Modulation & Coding Schemes MCS-0 (BPSK) to MCS-12 (16-QAM)
Latency < 1 ms
Maximum EIRP 38 dBm
Antenna
Gain 22.5 dBi
Type Integrated
Beamforming Scan Range +/- 140º azimuth, +/- 20º elevation
Beam Width 12º
Powering
Type Passive PoE (42-57 V)
Power Consumption 60 W with AUX PoE Out in use, 35 W without AUX PoE Out in use
Physical
EnvironmentalIP66/67
Temperature -40ºC to 60ºC (-40ºF to 140ºF)
Mean Time Between Failure > 40 years
Weight 0.25 kg (0.55 lbs)
Dimensions
W x H x D
15 cm x 10 cm x 25 cm
Wind Survival 200 km/h (124 mi/h)

Cambium Networks C600500C001A

60GHz cnWave V1000 Client Node with US cord

Cambium Networks’ 60 GHz cnWave solution provides easy, fast and cost-effective wireless gigabit connectivity for edge access and/ or high-capacity backhaul for edge access solutions at a significantly lower TCO than fiber infrastructure. Service providers and enterprises now have access to gigabit for business and residential connectivity, backhaul for Wi-Fi access or LTE/5G small cell. Certified for Facebook Terragraph, cnWave mesh solutions are highly efficient at handling high-density deployments in cities and suburban areas.

CLOUD AND ON-PREMISES MANAGEMENT

60 GHz cnWave operates wtih Cambium Networks’ cnMaestro management system. cnMaestro™ is a cloud-based or on-premises software platform for secure, end-to-end network control. cnMaestro wireless network manager simplifies device management by offering full network visibility and zero-touch provisioning. View and perform a full suite of wireless network management functions in real time. Optimize system availability, maximize throughput and meet emerging needs of business and residential customers.


Features:

  • Supports 57 to 66 GHz
  • Dual-sector with 280º coverage
  • Up to 15.2 Gbps (7.6 Gbps UL and 7.6 Gbps DL) with channel bonding
  • TDMA/TDD channel access and Network Synchronization
  • 802.11ay technology with Terragraph certification
