  • Cambium XE5-8 Indoor Tri-band WiFi 6e AP with multi-radio SDR 8x8. 5GbE (US Version)

Cambium XE5-8 Indoor Tri-band WiFi 6e AP with multi-radio SDR 8x8. 5GbE (US Version)

(0)No Reviews yet
  • SKU: XE5-8X00A00-US
  • Manufacturer: Cambium Networks
  • Data Sheet: Download

Product Information

Cambium Networks XE5-8X00A00-US

XE5-8 Indoor Tri-band WiFi 6e AP with multi-radio SDR 8x8. 5GbE. (US Version)

The Cambium XE5-8 Wi-Fi 6/6E Indoor Access Point is a five-radio Wi-Fi 6/6E 8x8/4x4 access point (AP) designed to deliver high-density, future-proof performance for building next generation wireless networks. With five user servicing radios, the XE5-8 delivers the highest density Wi-Fi 6 solution in the industry. Wi-Fi 6E support extends the capacity of Wi-Fi into the 6 GHz band, more than tripling the wireless spectrum available.

With high-speed software-defined radios, the XE5-8 enables seamless transition to Wi-Fi 6E with the ability to easily change from dual-band to tri-band (2.4 GHz, 5 GHz, 6 GHz) support when sufficient 6 GHz clients are available. The XE5-8 is fully backward compatible with existing Wi-Fi technology, enabling simultaneous support of new high speed clients, legacy clients, low-bitrate IoT devices, and more in a single wireless infrastructure.

The XE5-8 comes with Limited Lifetime Warranty providing return and repair service on the access point from date of purchase until end of life of the product.


XE5-8 operates with either Cambium Networks’ XMS or cnMaestroTM management system. Choose the management system that best fits your business and use the latest technology from Cambium Networks.


cnMaestro™ Essentials and X

  • Fixed Wireless Broadband, Wi-Fi and Switching
  • Help desk troubleshooting tools
  • Cloud managed Guest Access


  • Wi-Fi and Switching
  • Real-time and historical analytics
  • EasyPass™ User and Device Onboarding
  • Application Visibility and Control



RadiosTwo: 4x4 5/6 GHz 802.11a/n/ac/ax, SW configurable to 5 or 6GHz operation Two: 4x4 5 GHz 802.11a/n/ac/ax, SW configurable to one 8x8 radio One: 4x4 2.4 GHz 802.11 b/g/n/ax BLE 4.1
Wi-Fi802.11 a/b/g/n/ac Wave 2/ax
SSID SecurityWPA3, WPA2 (CCMP, AES, 802.11i), WPA2 Enterprise (802.1x/EAP), WPA PSK (TKIP),WEP, Open
Ports2 x IEEE 10/100/1000/2500/5000 Mbps Ethernet 1 x USB 3.0
Antenna6 GHz: 5.82 dBi, Omni 5 GHz: 5.61 dBi, Omni 2.4 GHz: 4.58 dBi, Omni
Max EIRP6 GHz: 30 dBm 5 GHz: 33 dBm 2.4 GHz: 30 dBm
PowerMax 59W 802.3bt powered device
Dimensions300 mm x 300 x 58 mm (without bracket) (11.81 in x 11.81 x 2.28 in )
Weight1.8 kg (3.97 lbs)
SecurityKensington lock slot
LEDsMulti-color status LEDs
Ambient Operating Temperature0ºC to 50ºC (32ºF to 122ºF)
Storage Temperature-40ºC to 70ºC (-40ºF to 158ºF)
Humidity95% RH non-condensing
MTBF668,759 hours 25ºC 314,145 hours at 50ºC
Mount OptionsWall or ceiling, T-bar with included locking bracket, ceiling tile plate
CertificationsFCC, IC, CE, EN 60601-1-2, EN 60950-1, IEC 62368-1 Safety, EN 60601-1-2 Medical EMC, EN 61000-4-2/3/5 Immunity, EN 50121-1 Railway EMC, EN 50121-4 Railway EMC, IEC 61373 Railway Shock & Vibration, EN 62311 Human Safety/RF Exposure, WEEE & RoHS
