Grandstream 1-port FXS Analog Telephone Adapter

(0)No Reviews yet

Out of Stock

1000 in stock
Austin TX
1000 In stock

Product Information

Grandstream HT801

1-port FXS Analog Telephone Adapter

The HT801 is a single port analog telephone adapter (ATA) that allows users to create a high-quality and manageable IP telephony solution for residential and office environments. Its ultra-compact size, voice quality, advanced VoIP functionality, security protection and auto provisioning options enable users to take advantage of VoIP on analog phones. It also allows service providers to offer high quality IP service to their market. The HT801 is an ideal ATA for individual use as well as commercial IP voice deployments worldwide.


Features:

  • Supports 1 SIP profile through a single FXS port and a single 10/100Mbps port
  • TLS and SRTP security encryption technology to protect calls and accounts
  • Automated provisioning options include TR-069 and XML config files
  • Supports 3-way voice conferencing
  • Failover SIP server automatically switches to secondary server if main server loses connection
  • Supports T.38 Fax for creating Fax-over-IP
  • Supports a wide range of caller ID formats
  • Use with Grandstream’s UCM series of IP PBXs for Zero Configuration provisioning
  • Supports advanced telephony features, including call transfer, call forward, call-waiting, do not disturb, message waiting indication, multilanguage prompts, flexible dial plan and more

Specifications

Specifications HT801

Interfaces
Telephone InterfacesOne (1) FXS port
Network InterfacesOne (1) 10/100Mbps auto-sensing ethernet port (RJ45)
LED IndicatorsPOWER, INTERNET, PHONE
Factory Reset ButtonYes
Voice, Fax, Modem
Telephony FeaturesCaller ID display or block, call waiting, flash, blind or attended transfer, forward, hold, do not disturb, 3-way conference
Voice CodecsG.711 with Annex I (PLC) and Annex II (VAD/CNG), G.723.1, G.729A/B, G.726, iLBC, OPUS, dynamic jitter buffer, advanced line echo cancellation
Fax Over IPT.38 compliant Group 3 Fax Relay up to 14.4kpbs and auto-switch to G.711 for Fax Pass-through
Short/Long Haul Ring Load2 REN: Up to 1km on 24 AWG
Caller IDBellcore Type 1 & 2, ETSI, BT, NTT, and DTMF-based CID
Disconnect MethodsBusy Tone, Polarity Reversal/Wink, Loop Current
Signaling
Network ProtocolsTCP/IP/UDP, RTP/RTCP, HTTP/HTTPS, ARP/RARP, ICMP, DNS, DHCP, NTP, TFTP, TELNET, STUN, SIP (RFC3261), SIP over TCP/TLS, SRTP, TR-069
QoSLayer 3 (ToS, DiffServ, MPLS)
DTMF MethodIn-audio, RFC2833 and/or SIP INFO
Provisioning and ControlHTTP, HTTPS, TELNET, TFTP, TR-069, secure and automated provisioning using AES encryption, syslog
Security
MediaSRTP
ControlTLS/SIPS/HTTPS
ManagementSyslog support, telnet, remote management using web browser
Physical
Universal Power Supply Input100-240VAC, 50-60Hz
Output5.0VDC/1.0A
Environmental
Operational32º – 104ºF or 0º – 40ºC
Storage14º – 140ºF or -10º – 60ºC
Humidity10 – 90% Non-condensing
Dimension100mm x 100mm x 29.5mm
Weight0.7 lb
Compliance
FCCPart15B
CEEN55032, EN55024, EN61000-3-2, EN61000-3-3, EN60950-1
RCMAS/NZS CISPR22, AS/NZS60950.1, S003
