KP Performance 900 MHz Dual Pol 12.5 dBi 90 Degree Sector with PMP Mounting Bracket

(0)No Reviews yet
  • SKU: KPPA-900DP-90S-PMP
  • Manufacturer: KP Performance
  • Data Sheet: Download
  • Installation Guide:Download

Product Information

KP Performance KPPA-900DP-90S-PMP

900 MHz Dual Pol 12.5 dBi 90 Degree Sector with PMP Mounting Bracket

The KP Performance KPPA-900DP-90S-PMP is a 900 MHz Dual pol sector antenna that has been constructed with heavy duty aluminum extrusion and covered with a UV resistant ABS radome. The NLOS KPPA-900DP-90S-PMP dual polarized antenna is very well suited for communicating with fixed and mobile wireless clients. The size of this sector antenna will allow you to install four sectors on one small tower, its 38 x 9.5 x 3 inches and weighs only 12 Ibs. Because of its high gain it offers superior extended range. The 90 degree beamwidth covers a large service area. The heavy duty mounting system will ensure a stable installation in high wind conditions. The mount has a tilt indicator to enable setting of accurate antenna down tilt.


Features:

  • 900MHz dual polarized sector directional antenna
  • 12.5 dBi gain , 90 degree beamwidth
  • Type N female integrated connector
  • Smallest sector antenna on the market
  • Heavy duty mounting brackets

Specifications

Specifications KPPA-900DP-90S-PMP

Frequency Range824 MHz to 928 MHz
Polarization Type45 Deg. Slant
Gain12.5 dBi
Vertical Beamwidth19°
Horizontal Beamwidth90°
Electrical Downtilt
F/B Ratio28 dB
VSWR1.5:1
Cross Polar Ratio20 dB
Port Isolation25 dB
Connector Type2 x Type N Female
Dimension 39 in L x 13.5 in W x 9.5 in H
Weight 36 lbs
