MikroTik CubeSA 60Pro ac A sector antenna to connect multiple 60 GHz devices (US Version)
- SKU: CubeG-5ac60ay-SA-US
Product Information
MikroTik RouterBOARD CubeG-5ac60ay-SA (US Version)
CubeSA 60Pro ac A sector antenna to connect multiple 60 GHz devices
If you need to connect multiple devices – take a look at the CubeSA 60Pro ac sector antenna. Reaching distances around 600 meters in point-to-multipoint mode, this device can be very helpful for all kinds of event management: from live shows, festivals, and workshops to construction sites, pop-up vaccination clinics, and so on. No need for complex wired installations in every location – the portable and handy CubeSA 60Pro ac has got you covered! Depending on your setup, the distance can be even greater. For example, with devices like MikroTik nRAY, you can reach up to 800 meters.
Forget about downtime with the automatic 5 GHz backup connection The 60 GHz frequency is unaffected by the crowded wireless spectrum, it offers high speed and capacity. But it can sometimes struggle during bad weather conditions. That’s why both Cube 60Pro devices feature an automatic 5 GHz failover. We have added a powerful directional antenna so that the 5 GHz range can keep up with the 60 GHz.
More durability, less unwanted attention We have upgraded the enclosure to feature a strong metal base – for better mounting and cooling options. The Cube form-factor emerges from pure practicality: it is durable, unobtrusive, and compact.
Features:
- Gigabit Ethernet
- 4 Powerful quad-core CPU
- 5 GHz failover
- Reach greater distance than ever with channel 5 support
- TDMA GPS sync
- Improved design and mounting options
- 60 GHz 802.11ay, compatible with previous 802.11ad products
Specifications
Specifications CubeG-5ac60ay-SA-US
CPU | 4 core IPQ-4019 716 MHz |
Size of RAM | 256 MB |
Storage | 64 MB flash |
Number of 1G Ethernet ports | 1 |
Wireless | 5 GHz 802.11a/n/ac |
Wireless Chains | 1 |
Antenna gain (dBi) | 11.5 5 GHz |
Antenna beam width | 35° 5 GHz |
Antenna beam width at 60 GHz | 11° (CubeG-5ac60ay); 60° (CubeG-5ac60ay-SA) |
GPS | MT3337V |
WiGig chipset | QCA6438 |
WiGig antenna module | SWL-QD46 |
Supported protocol | MikroTik 802.11ad / 802.11ay |
Max EIRP (dBm) | 40 |
Dimensions | 115 x 211 x 90 mm (Cube G-5ac60ay-SA) 4.52" x 8.30" x 3.54" |
Operating temperature | -40°C to +70°C |
Operating system | RouterOS, License level 4 |
Certification & Approvals | |
Certification | CE, FCC, IC |
Powering | |
PoE-in | 802.3af/at |
Supported input voltage | 18-57 V |
Power adapter nominal voltage | 24 V |
Power adapter nominal current | 0.8 A |
Max power consumption | 13 W |
Wireless specifications | ||
Rate (5 GHz) | Tx (dBm) | Rx (dBm) |
6MBit/s | 22 | -93 |
54MBit/s | 18 | -74 |
MCS0 | 22 | -93 |
MCS7 | 17 | -71 |
MCS9 | 15 | -68 |
