MikroTik RouterBOARD SXTR&FG621-EA

SXT LTE6 kit (RouterOS L3) with FG621-EA card, International Version

SXT LTE6 kit is an update of our timeless device for remote locations that are within cellular network coverage. It features the same modern Category 6 LTE chip that you might have seen in our latest devices – like the popular Chateau LTE6 ax! Not only this LTE chip can provide reliable Internet connectivity for your building even where cell phones fail, it also allowed us to drive the price for this kit way down. Mount an SXT outside your home – and always stay connected!

You’re getting the classic, fundamental design that has stood the test of time. Weatherproof. Unobtrusive. Snow-resistant. With a modern LTE6 card for uninterrupted mobile connectivity. And a price around 30% lower than the original SXT LTE6 kit. Furthermore, we offer significant project discounts and custom branding options on volume orders. The best price on the market becomes even better!

We’ve included two Micro-SIM slots – for backup. It never hurts to have extra options when it comes to mobile network coverage. Also, the Category 6 LTE modem enables carrier aggregation, allowing SXT to use multiple LTE bands simultaneously. That’s a huge advantage when there are a lot of mobile users in the area. It offers better responsiveness in a crowded environment. And higher efficiency for weaker signal situations in the countryside. Win-win! We have seen Internet speed doubling in rural areas after switching to CAT6, so there is no need to wait for cable network expansions.

The unit is equipped with two Ethernet ports and PoE functionality: PoE-in on Ether1, PoE-out on Ether2. That means SXT can power other devices or be powered by other devices, making your cable management so much easier! Unit is shipped with a 24 V power supply, but can support a wide range of 12-57 V and is 802.3af/at compliant.

Specifications

Specifications

CPUQCA9531 650 MHz
CPU architectureMIPSBE
CPU core count1
Size of RAM64 MB
RAM typeDDR2
Storage16 MB, Flash
Number of 100M Ethernet ports2
MiniPCIe slots1
LTE category6 (300Mbit/s Downlink, 50Mbit/s Uplink)
LTE modemR11eL-FG621-EA
TAC86335904
LTE FDD bands1 (2100MHz) / 3 (1800MHz) / 5 (850MHz) / 7 (2600MHz) / 8 (900MHz) / 20 (800 MHz) / 28 (700MHz)
LTE TDD bands38 (2600MHz) / 40 (2300MHz) / 41 (2500MHz)
MIMO DL2x2
MIMO UL1x1
3G CategoryR8 (42.2Mbps Downlink, 11.2Mbps Uplink)
3G Bands1 (2100MHz) / 3 (1800MHz) / 5 (850MHz) / 8 (900MHz)
Dimensions

140 x 140 x 56 mm

5.51 x 5.51 x 2.20 inch

Operating systemRouterOS v7, License level 3
Operating temparature-40°C to +60°C
Powering
Number of DC inputs1
PoE-inYes, on Ether1
PoE-OutYes on Ether2, max out per port output (input < 30 V): 600 mA, max out per port output (input > 30 V): 400 mA
Supported input voltage12-57 V (Passive PoE 802.3af/at on Ether1)
Power adapter nominal voltage24 V
Power adapter nominal current1.2 A
Max power consumption without attachments5 W
Max power consumption22 W
Supported 2xCA LTE bands
1+1/3/5/7/8/20/2840+40
3+3/5/7/8/20/288+8
5+5/738+38
7+7/8/20/2841+41
