TP-Link Omada Pro 4G+ Cat6 AX3000 Gigabit VPN Router
- SKU: G36W-4G
$1,299.99
Product Information
TP-Link G36W-4G
Omada Pro 4G+ Cat6 AX3000 Gigabit VPN Router
Omada Pro is TP-Link's enterprise-grade product line designed to meet the high-capacity, security, and management needs of various industries. It provides one-stop professional cloud solutions, integrating a complete set of devices such as access points, switches, and routers. It’s ideal for diverse vertical industries including multi-dwelling units (MDUs), K-12 education, hospitality, public works, catering, manufacturing, malls, and more.
Features:
- Support 4G+ Cat6: Insert a Nano SIM card to enjoy up to 300 Mbps.
- AX3000 Dual-Band WiFi 6: Supports 2402 Mbps on 5 GHz and 574 Mbps on 2.4 GHz
- 6 Gigabit Ethernet Ports: Provide high-speed wired connectivity.
- 5 High-Gain Detachable Antennas: Extend and concentrate the Wi-Fi and 4G+ LTE signals.
- Centralized Management: Cloud access and the Omada app for easy management.
- Omada Pro Mesh: Seamlessly connects to Omada Pro EAPs that support mesh technology.
- High-Security VPN: Supports IPSec / SSL / WireGuard / OpenVPN / PPTP / L2TP△ / GRE† VPN.
Specifications
Specifications G36W-4G
| Hardware | |
| Standards and Protocols | IEEE 802.3, IEEE802.3u, IEEE802.3ab, IEEE802.3z, IEEE 802.3x, IEEE 802.1q, TCP/IP, DHCP, ICMP, NAT, PPPoE, NTP, HTTP, HTTPS, DNS, IPSec, PPTP, L2TP, OpenVPN, WireGuard VPN, GRE VPN, SNMP, 802.11a/b/g/n/ac/ax |
| Interface | 1 Gigabit SFP WAN/LAN Port 1 Gigabit WAN Port 4 Gigabit LAN/WAN Ports |
| LTE | 1 Nano SIM slot (4G+ Cat6) |
| LTE Speed | Downlink: 300 Mbps, Uplink: 50 Mbps |
| Wi-Fi Speed | 2.4 GHz: 574 Mbps 5 GHz: 2402 Mbps HE160 |
| Antennas | Wi-Fi: Three 5GHz 5.5dBi & 2.4GHz 4.5dBi dual-band detachable antennas LTE: Two 4.0dBi omnidirectional detachable antennas |
| Network Media | 10BASE-T: UTP category 3, 4, 5 cable (Max 100 m) EIA/TIA-568 100Ω STP (Max 100 m) 100BASE-TX: UTP category 5, 5e cable (Max 100 m) EIA/TIA-568 100Ω STP (Max 100 m) 1000BASE-T: UTP category 5, 5e, 6 cable (Max 100 m) |
| Network Type | LTE Band of EU: 4G LTE-FDD: B1/B3/B5/B7/B8/B20/B28/B32 (2100/1800/850/2600/9 00/800/700/1450 MHz) 4G LTE-TDD: B38/B40/B41 (2600/2300/2500 MHz) 3G DC-HSDPA/HSPA+/HSDPA/HSUPA/WCDMA: B1/B3/B5/B8 (2100/1800/850/900 MHz) Carrier Aggregation: B1+B1/B3/B5/B7/B8/B20/B28/B38/B40/B41 B3+B3/B5/B7/B8/B20/B28/B38/B40/B41 B5+B5/B7/B38/B40/B41 B7+B7/B8/B20/B28/B32 B8+B32/B38/B40/B41 B20+B32/B38/B40 B28+B32/B38/B40/B41 B38+B38 B40+B40 B41+B41 |
| Network Type | LTE Band of US: 4G LTE-FDD: B2/B4/B5/B7/B12/B13/B14/B25/B26/B29/B30/B66/B71 (1950/2100/850/2600/750/750/750/1950/850/700/2350/2150/650 MHz) 4G LTE-TDD: B41/B48 (2500/3600 MHz) Carrier Aggregation: B2+B2/B4/B5/B7/B12/B13/B14/B29/B30/B48/B66/B71 B4+B4/B5/B7/B12/B13/B29/B30/B71 B5+B5/B7/B25/B30/B41/B66 B7+B7/B12/B66 B12+B12/B25/B30/B66 B13+B66 B14+B30/B66 B25+B25/B26/B41 B26+B41 B29+B30/B66 B30+B66 B41+B41 B48+B48 B66+B66/B71 |
| Button | Reset button |
| Power Supply | 12VDC / 2A Power Adapter |
| Flash | 128 MB NAND |
| DRAM | 512 MB DDR4 |
| LED | SYS, WLAN, SFP, LTE Signal, WAN (1000M Link/Act, 100/10M Link/ Act), WAN/LAN (1000M Link/Act, 100/10M Link/Act) |
| Max Power Consumption | EU: 15.4W US: 17.3W |
| Surge Protection | 4 kV surge protection |
| Mounting | Desktop/ Wall-mounting |
| Dimensions ( W x D x H ) | 8.9 × 5.2 × 1.4 in (226 × 131 × 35 mm) (Antenna dimensions not included) |
| SDN Support | |
| Hardware Controller | Automatic Device Discovery Intelligent Network Monitoring Abnormal Event Warnings Unified Configuration Reboot Schedule Captive Portal Configuration |
| Concurrent Session | 150000 |
| New Sessions /Second | 5100 |
| Static IP NAT Throughput (Upload / Download) | 947.1Mbps/940.1Mbps |
| DHCP NAT Throughput (Upload / Download) | 949.2Mbps /941.1Mbps |
| PPPoE NAT Throughput (Upload / Download) | 942.6Mbps/941.1Mbps |
| L2TP NAT Throughput (Upload / Download) | 875.4Mbps/892.0Mbps |
| PPTP NAT Throughput (Upload / Download) | 881.2Mbps/895.8Mbps |
| 66 Byte Packet forwarding rate (Upload / Download) | 1,453,489 pps / 1,453,488 pps |
| 1,518 Byte Packet forwarding rate (Upload / Download) | 81274 pps/ 91275 pps |
| IPSec VPN Throughput | ESP-SHA1-AES256: 652.2Mbps ESP-SHA256-AES256: 654.4Mbps ESP-SHA384-AES256: 646.5Mbps ESP-SHA512-AES256: 670.5 Mbps |
| GRE | Unencrypted: 545.3Mbps Encrypted: 282.6Mbps |
| WireGuard VPN | 387.7Mbps |
| SSL VPN | 122.5Mbps |
| OpenVPN | 115.5Mbps |
| L2TP VPN Throughput | Unencrypted: 990.0Mbps Encrypted: 475.0Mbps |
| PPTP VPN Throughput | Unencrypted: 1177.9Mbps Encrypted: 177.4Mbps |
| Basic Functions | |
| WAN Connection Type | Static IP Dynamic IP PPPoE (supports MRU Configuration) PPTP L2TP |
| DHCP | DHCP Server DHCPv6 PD Server (only in Standalone Mode) DHCP Options Customization DHCP Address Reservation Multi-IP Interfaces Multi-Net DHCP |
| MAC Clone | Modify WAN Address |
| IPTV | IGMP v2/v3 Proxy, Custom Mode, Bridge Mode |
| IPv6 | StaticIP / SLAAC / DHCPv6 / PPPoE / 6to4Tunnel / PassThrough / Non- Address mode |
| Stateful ACL | √ |
| mDNS Repeater | √ |
| Quality of Service | √ |
| Bridge VLAN | √ |
| VLAN | 802.1Q VLAN |
| SMS | Receive/Send SMS |
| DNS Queries | √ |
| Wildcard FQDN | √ |
| Wireless Function | |
| Wireless Encryption | WPA/WPA2/WPA3 Personal, WPA/WPA2/WPA3 Enterprise |
| Multiple SSIDs | 16 in total (8 per radio) |
| Enable/Disable Wireless Radio | √ |
| Enable/Disable SSID Broadcast | √ |
| Guest Network | √ |
| Automatic Channel Selection Algorithm | √ |
| Transmit Power Control | Adjust transmit Power on dBm |
| Seamless Roaming | √ |
| Mesh | √ (with EAP that supports Mesh) |
| OFDMA | √ |
| Beamforming | √ |
| MU-MIMO | √ |
| Rate Limit | Based on SSID/Client |
| Load Balance | √ |
| Airtime Fairness | √ |
| Band Steering | √ |
| RADIUS Accounting | √ |
| MAC Authentication | √ |
| Reboot Schedule | √ |
| Wireless Schedule | √ |
| Support Data Rates | 802.11ax: 8 Mbps to 2402 Mbps (MCS0-MCS11, NSS = 1 to 2 HE20/40/80/160) 802.11ac: 6.5 Mbps to 2166.7 Mbps (MCS0-MCS11, NSS = 1 to 2 VHT20/40/80/160) 802.11n: 6.5 Mbps to 300 Mbps (MCS0-MCS15, HT20/40) 802.11g: 6, 9, 12, 18, 24, 36, 48 ,54 Mbps 802.11b: 1, 2, 5.5, 11 Mbps 802.11a: 6, 9, 12, 18, 24, 36, 48 ,54 Mbps |
| G36W-4G | |
| Load Balance | Intelligent Load Balance Application Optimized Routing Link Backup (Timing, Failover) Online Detection |
| NAT | One-to-One NAT Multi-Net NAT Virtual Server Port Triggering1 NAT-DMZ FTP/H.323/SIP/IPSec/PPTP ALG UPnP |
| Routing | Static Routing Policy Routing RIP2 OSPF2 |
| Session Limit | IP-based Session Limit |
| Bandwidth Control | IP-based Bandwidth Control |
| IPSec VPN | 100 IPSec VPN Tunnels LAN-to-LAN, Client-to-LAN Main, Aggressive Negotiation Mode DES, 3DES, AES128, AES192, AES256 Encryption Algorithm IPsec Failover IKE v1/v2 MD5, SHA1, SHA2-384 and SHA2-512 Authentication Algorithm NAT Traversal (NAT-T) Dead Peer Detection (DPD) Perfect Forward Secrecy (PFS) |
| PPTP VPN | PPTP VPN Server PPTP VPN Client (10)3 50 Tunnels PPTP with MPPE Encryption |
| L2TP VPN | L2TP VPN Server L2TP VPN Client (10)3 50 Tunnels L2TP over IPSec |
| GRE | Only in Standalone Mode |
| WireGuard VPN | √ |
| SSL VPN | 50 Tunnels |
| OpenVPN | OpenVPN Server OpenVPN Client (5)3 55 OpenVPN Tunnels ""Certificate + Account"" Mode Full Mode |
| Attack Defense | TCP/UDP/ICMP Flood Defense Block TCP Scan (Stealth FIN/Xmas/Null) Block Ping from WAN |
| Filtering | Web Group Filtering1 URL Filtering Web Security1 |
| DNS Proxy | DNSSEC, DoH, and DoT |
| ARP Inspection | Sending GARP Packets ARP Scanning2 IP-MAC Binding |
| Access Control | Source/Destination IP Based Access Control |
| DPI | Application Control, Traffic Monitor |
| IDS/IPS | Intrusion detection systems (IDS) and intrusion prevention systems (IPS) |
| Web Authentication | No Authentication Simple Password3 Hotspot (Local User / Voucher3 / SMS3 / Radius3) External Radius Server External Portal Server3 LDAP |
| Service | Dynamic DNS (Dyndns, No-IP, Peanuthull, Comexe, DDNS Customization) |
| Maintenance | Web Management Interface Remote Management Export & Import Configuration SNMP v1/v2c/v3 Diagnostics (Ping & Traceroute)4 NTP Synchronize4 Port Mirroring CLI (only in Standalone Mode) Syslog Support Intelligent anomaly detection Gateway Online Detection Remote Packet Capture |
| Certification | CE, FCC, RoHS |
| Package Contents | G36W-4G, Power Adapter, Quick Installation Guide |
| System Requirements | Microsoft Windows 98SE, NT, 2000, XP, Vista™ or Windows 7/8/8.1/10/11 MAC OS, NetWare, UNIX or Linux |
| Environment | Operating Temperature: 0 °C to 40 °C (32 °F to 104 °F) Storage Temperature: -40 °C to 70 °C (-40 °F to 158 °F) Operating Humidity: 10% to 90% non-condensing Storage Humidity: 5% to 90% non-condensing |
