Tycon Power Input, 24VDC 3A 70W Output Voltage Converter
- SKU: TP-VRHP-1224
$80.70 $84.95
- Manufacturer: Tycon Power
- Spec Sheet: Download
Product Information
TP-VRHP-1224 10-15VDC
Input, 24VDC 3A 70W Output Voltage Converter
The TP-VRHP-1224 is a 70W voltage converter/regulator which accepts an input of plus or minus 10VDC to 15VDC and provides a regulated output of 24VDC @ 1.25A 70W. These units are perfect for providing 24VDC voltage from 12VDC battery sources like in a vehicular application or remote power. Input and outputs are wire terminals for wire up to 12AWG. Operates from -30 to +65 deg C.
Features:
- High Output, Short Circuit Protected
- Metal Enclosure, DIN rail mounting
- Industrial Temperature Operation
- Most Models Isolated Input to Output
- Low Voltage Disconnect
Applications:
- Security Systems
- Remote Power Systems
- Telecom Applications
- Wireless Base Stations
Specifications
Specifications TP-VRHP-1224
| DC Input Voltage Range | +/- 10 to 15VDC |
| DC Voltage Output | 24VDC @ 2.9A |
| Maximum Power | 70W |
| Efficiency | >85% |
| Load / Line Regulation | 5% / 1% |
| Ripple / Noise | 2% / 5% |
| Wire Gauge | 12AWG Max |
| Isolation Voltage / Ohms | 1500VDC Min. / 100M Ohms Min |
| Protections | Short Circuit, Overvoltage, Overload |
| Operating Temp | -22 to 149deg F (-30 to +65deg C) |
| Operating Humidity | 0 to 90% RH |
