Ubiquiti Networks Unifi SmartPower Strip 6-Ports US
- SKU: USP-STRIP-US
$49.00
- Manufacturer: Ubiquiti Networks
- Data Sheet: Download
Product Information
Ubiquiti Networks USP-STRIP-US
Unifi SmartPower Strip 6-Ports US
The SmartPower Strip is designed to monitor and manage multiple remote AC power connections and supports internet outage recovery.
The UniFi SmartPower Strip is a Wi-Fi connecter power strip installed between an AC outlet and the power plugs of your internet connectivity hardware (modems, router, etc). The UniFi Network Controller continuously monitors availability of an internet connection. If the connection drops, the UniFi SmartPower Plug automatically restarts the connected devices by disconnecting power for a short period of time*.
The UniFi SmartPower Strip offers six power control outlets for 125VAC devices (up to 1250W total). Four USB Type A ports can charge smartphones, reading lights, and other devices (up to 1A per port).
Features:
- Attempt to automatically recover from Internet outages.
- (6) AC power outlets enabling remote monitoring and restarts.
- (4) USB-C ports supporting a total power budget of 20W.
- Integrated circuit breaker for current protection.
Specifications
Specifications USP-STRIP-US
| Mechanical | |
| Dimensions | 229.5 x 111.5 x 37.8 mm (9 x 4.4 x 1.5") |
| Weight | Without mount: 702 g (1.6 lb) With wall mount: 849 g (1.9 lb) |
| Enclosure material | Fire-retardant plastic |
| Mount material | Fire-retardant plastic |
| Mounting | Magnetic wall mount (Included) |
| Hardware | |
| Management interface | 2.4 GHz WiFi |
| Networking interface | 802.11 b/g/n WiFi |
| Power method | AC input |
| Power supply | AC/DC embedded |
| Supported voltage range | AC input/output: 125V~10A Max., 60 Hz |
| Max. power consumption | 1250W for 125V AC |
| Power output | (6) Power control outlets,125V, 1250W Max. total (4) USB Type C ports, 2A Max. per Port, 20W Max. total |
| Operating frequency | 2.4 GHz |
| Antenna | Single-band |
| Max. TX power | 16.9 dBm |
| MIMO | 1 x 1, 2 x 1 |
| ESD/EMP protection | Air/contact: ± 24 kV |
| Buttons | (1) Factory reset (1) Circuit breaker |
| LEDs | (1) Power: blue/white Flashing white: bootup in progress Flashing blue: firmware upgrading Steady white: factory defaults, waiting adoption Steady blue: device is adopted |
| Ambient operating temperature | 0 to 40° C (32 to 104° F) |
| Ambient operating humidity | 10 to 90% noncondensing |
| Certifications | FCC, IC |
| Software | |
| WiFi standards | 802.11 b/g/n |
| Power save | Yes |
| Wireless security | WPA2-PSK AES/TKIP |
| Supported Data Rates (Mbps) | |
| 802.11b | 1, 2, 5.5, 11 Mbps |
| 802.11g | 6, 9, 12, 18, 24, 36, 48, 54 Mbps |
| 802.11n | 6.5 - 72.2 Mbps (MCS0 - MCS7, HT 20) |
