Ubiquiti Networks UniFi Compact 5-Port Gigabit Switch Flex Mini (3-pack)
US$85.00
- SKU: USW-FLEX-MINI-3
- Manufacturer: Ubiquiti Networks
- Data Sheet: Download
Product Information
Ubiquiti Networks USW-Flex-Mini-3
Layer 2 switch with (5) GbE RJ45 ports, including (1) 802.3af PoE input.
The Switch Flex Mini (USW Flex Mini) is a fully managed, Layer 2 switch with (5) GbE RJ45 ports, including (1) 802.3af PoE input. The USW Flex Mini can be powered with either PoE (via Port 1) or its included USB-C power adapter*. This switch can also be monitored or configured from anywhere with the powerful, intuitive UniFi Network web application and mobile app.
Features:
- (1) GbE, 802.3af PoE RJ45 input
- (4) GbE RJ45 ports
- Compact, slim housing
- Can be powered with a 5V, 1A USB-C adapter
Works with the UniFi Network Application:
- Centrally manage multiple networks from an intuitive interface
- Enjoy real-time device insights and deep configuration options
- Upgrade device firmware remotely
- Manage network users and guests with ease
- Personalize the design, architecture, and privacy of guest hotspots
- Set up devices quickly and manage them on the go with a powerful mobile app
Specifications
Specifications USW-Flex-Mini-3
| Dimensions | 107.16 x 70.15 x 21.17 mm (4.22 x 2.76 x 0.83") |
| Weight | 150 g (5.29 oz), 0.33lb |
| Interfaces | |
| Networking | (5) 10/100/1000 Mbps RJ45 Ports |
| PoE In | 802.3af/at PoE (Pins 1, 2+; 3, 6-) |
| Management | Ethernet In-Band |
| Total Non-Blocking Throughput | 5 Gbps |
| Switching Capacity | 10 Gbps |
| Forwarding Rate | 7.44 Mpps |
| Power Method | USB Type C, 5V 802.3af/at PoE (44 - 57VDC, 0.05 - 0.04A) |
| Power Supply | 5V, 1A Power Adapter* |
| Voltage Range | |
| USB Type C | 4.7 - 5.3VDC |
| 802.3af/at PoE | 44 - 57VDC |
| Max. Power Consumption | 2.5W |
| LEDs | |
| System | Status |
| RJ45 Data Ports | Speed/Link/Activity |
| ESD/EMP Protection | ± 16kV Air, ± 12kV Contact |
| Shock and Vibration | ETSI300-019-1.4 Standard |
| Operating Temperature | -5 to 45° C (23 to 113° F) |
| Operating Humidity | 10 to 90% Noncondensing |
| Certifications | CE, FCC, IC |
