APC Smart-UPS X-Series 48V External Battery Pack Rack/Tower

  • Manufacturer: APC
  • Data Sheet: Download
  • Installation Guide: Download
  • Availability: Call for Availability This item can sometimes be sourced and shipped direct from other locations when out of stock. Email me when this product is in stock!


Smart-UPS X-Series 48V External Battery Pack Rack/Tower

Extended-run battery systems provide flexible runtime to critical Smart-UPS applications.

Hot-swappable batteries Ensures clean, uninterrupted power to protected equipment while batteries are being replaced

Intelligent battery management Maximizes battery performance, life, and reliability through intelligent, precision charging.

Rack/Tower convertible Protects the initial investment in the UPS when migrating from tower to rack-mount environment.

Smart-UPS Battery Systems Features & Benefits

Multiple battery pack configuration Connect up to 10 battery packs for extended runtime applications.

Advanced battery management included

Embedded monitoring at the cell, module, and cabinet level provides a clear picture of battery runtime and health, with the added benefits of predictable, consistent runtime performance and stable cell health.

Specifications SMX48RMBP2U

Battery Output Voltage 48 V
Nominal Input Voltage 48VDC
Batteries & Runtime
Battery type Lead-acid battery
Battery mounting Enclosed battery cartridge
Expected Battery Life (years) 3 - 5
RBC Quantity 2
Battery Volt-Amp-Hour Capacity 864
Maximum Height 89MM, 8.9CM
Maximum Width 432MM, 43.2CM
Maximum Depth 490MM, 0.0CM
Rack Height 2U
Net Weight 28.64KG
Shipping weight 35.5KG
Shipping Height 246MM, 24.6CM
Shipping Width 589MM, 58.9CM
Shipping Depth 620MM, 62.0CM
Color Black
Units per Pallet 8.0
Standard warranty 2 years repair or replace
Sustainable Offer Status
RoHS Compliant
