  • Attabox Heartland 6 x 6 x 4 inches AH664 Enclosure (Opaque Cover)

Attabox Heartland 6 x 6 x 4 inches AH664 Enclosure (Opaque Cover)

(0)No Reviews yet
US$‎96.69 US$‎121.04
  • SKU: AH664
  • Manufacturer: ATTABOX
  • Data Sheet: Download
1 in stock
College Station
1 In stock

Product Information

Attabox AH664

Attabox Heartland 6 x 6 x 4 inches AH664 Enclosure

Opaque Cover Configuration (Hinged, Latched, Padlockable)

Features:

  • Inches: 6 x 6 x 4 in
  • MM: 152 x 152 x 102 mm
  • Opaque Cover Configuration (Hinged, Latched, Padlockable)

Specifications

Specifications AH664

Material (Box & Cover)Polycarbonate with UV inhibitors
Cover Screw Size#10-32 x 5/8
Cover Screw Material304 Stainless Steel
Back Panel Screw Size#10-32x3/8
Cover Screw Torque20-24 in.-lbs.
Gasket MaterialNeoprene rope style
Hinge and Latch HardwarePolycarbonate with UV inhibitors
Metal InsertsAll threaded brass inserts accepting #10-32 screws
Mounting BossesPanel mounting capability for fixed rear panel
Mounting Feet Inserts1/4-20x1/2
Mounting Feet Torque14-16in.-lbs
Side Mount SolutionsVariable height side mount capability
Soft Edge DesignRounded edges, minimal protrusions or exposed pocket areas for assembly of dust and debris
INDUSTRY STANDARDS
Chemical ResistanceProvide Link to Chemical Resistance Charts
Flammability RatingUL94-5VA
Self ExtinguishingNon-halogenated, non-flame propagating
Temperature Range(-20°F to +240°F) (-29°C to +115°C)
UL/cUL File #E319779
Impact Rating (IK10)No
CSA Std. C22.2 File #No
IEC 60529 RatingsIP66
NEMA Ratings (UL508A, UL50 & UL50e)1, 3R, 4, 4X, 12
NFPA No. 101 Flame SpreadN/A
Outdoor UV Exposure (UL 746C)(f1) Rated
Plenum Space Rating (UL 2043) No
UL 1741 File #No
