Cambium Dual Band 5GHz/6GHz, 11dBi, 60 degree Beamwidth 4x4 Antenna with N-female Connectors
- SKU: ANT-D60-4X4-02
$250.00
+ $9.00 Tariff
- Manufacturer: Cambium Networks
Product Information
Cambium Networks ANT-D60-4X4-02
Dual band 5GHz/6GHz, 11dBi, 60 degree beamwidth 4x4 antenna with N-female connectors, bracket included, cables sold separately
The Performance and versatility of the Cambium Networks antenna, designed to meet the demands of modern WLAN networks. This flat panel, directional antenna offers a significant gain of 11 dBi, ensuring strong and stable signal transmission and reception over a wide frequency range of 5.15 - 7.125 GHz. Its design allows for easy mounting on both poles and walls, providing flexibility in placement to achieve the best signal direction and coverage.
Specifications
Specifications ANT-D60-4X4-02
| Frequency Range (GHz) | 5 GHz/6 GHz |
| Impedance | 50 ohms |
| Gain | 11 dBi |
| 3dB Beamwidth Az (H) | 60° Typ. |
| 3dB Beamwidth El (V) | 60° Typ. |
| Connector | N-Female x4 |
| Dimensions | 7.5in x 7.5in x 1.57in |
| Weight | 0.45 lbs |
| Operating Temp | -40° C to +55° C |
