Cambium 2.4 GHz PMP 450 Subscriber Module 10Mbps

  • SKU: C024045C002A
  • Manufacturer: Cambium Networks
  • Data Sheet: Download
  • Availability: Direct Ship Item Item usually ships same day direct from Manufacturer Email me when this product is in stock!

Specifications C024045C002A

Channel Spacing Configurable on 2.5 MHz increments
Frequency Range 2400 - 2483.5 MHz
Channel Width 5 MHz, 10 MHz or 20 MHz
Physical Layer 2x2 MIMO OFDM
Ethernet Interface 10/100BaseT, half/full duplex, rate auto negotiated (802.3 compliant)
Latency 3 - 5 ms
Antenna Beamwidth 55° azimuth, 55° elevation (both H&V)
Transmit Power -30 to +22 dBm (combined, to EIRP limit by region) (1 dB interval)
Antenna Gain 8 dBi Dual Slant, integrated patch
Max. Transmit Power 22 dBm combined
Reflector Gain+14 dBi
Antenna ConnectionIntegrated patch antenna
Temperature-40°F to 131°F (-40°C to 55°C)
Weight 1 lb (0.45kg)
Wind Survival118 mph (190 km/hour)
Dimensions 11.75" x 3.4" x 3.4" (30 x 9 x 9cm)
Max. Power Consumption 12W
Input Voltage 24 to 30V

Cambium Networks C024045C002A

2.4 GHz PMP 450 Subscriber Module 10Mbps

The Cambium Networks Point-to-Multipoint (PMP) 450 Access Point (AP) can provide more than 90 Mbps throughput and is interoperable with PMP 430 and PMP 100 Series Subscriber Modules (SM). Service providers with an installed base of PMP 100 subscribers can now migrate to new high-throughput PMP 450 modules to enhance overall capacity; allowing more users and/or higher rate plans.

Utilizing 2x2 MIMO-OFDM technology, new deployments can take advantage of Cambium Networks proprietary feature set, while achieving data rates higher than 90 Mbps. From the available synchronization options to its diverse feature set, the PMP 450 provides flexible deployment options that make it a good fit for high capacity, high reliability networks.

Cambium Networks provides exceptional wireless broadband connectivity solutions. With more than 3 million modules deployed in thousands of networks around the world, Cambium solutions are proven to provide cost effective, reliable data, voice and video connectivity.
