Cambium PTP 820S Radio 6LGHz, TR65A, Ch1W3, Hi, 5790-5820MHz

  • SKU: C060082B001A
  • Manufacturer: Cambium Networks
  • Data Sheet: Download
  • Availability: Open chat or call usEmail me when this product is in stock!
$‎3,500.00

Specifications C060082B001A

Description PTP 820S Radio 6LGHz,TR65A,Ch1W3,Hi,5790-5820MHz
Licensed Radio Series PTP 820S
Network Protocol IP
Broadband System Configuration All Outdoor
Broadband Frequency Band 6 GHz
Frequency Range 5790-5820 MHz
Sub Band Hi
Data Rate 605 Mbit/s
Maximum Data Rate 833 Mbit/s
Carrier Aggregation Single Carrier
Modulation QPSK to 2048 QAM w/ACM
Interface 1 x 10/100/1000Base-T and 1x1000base-X or 10/100/1000Base-T
Security/Encryption Not Specified
Compression No
Proprietary Antenna Interface Not Specified
Operating Voltage -48VDC
Channel Bandwidth 28,56,30,40,50,60,80 MHz
Temperature Range -33-55 deg C

Cambium Networks C060082B001A

PTP 820S Radio 6LGHz, TR65A, Ch1W3, Hi, 5790-5820MHz

PTP 820 is a point-to-point licensed microwave backhaul platform that integrates leading networking functionality with the industry’s most advanced microwave technologies creating a superior microwave transport solution. Supporting licensed frequency bands ranging from 6 to 42 GHz, the PTP 820 series delivers a wide range of configurations to offer a tailored solution for any deployment scenario. Composed of high-density multi-technology nodes and integrated radio units, the PTP 820 series offers flexibility in choosing all-indoor, split-mount and all-outdoor configuration options. Exploiting unique Line of Sight (LOS) Multiple Input Multiple Output (MIMO) technology, modulation up to 2048QAM and wider channel bandwidths, ensures Industry leading throughput and spectral efficiency.
