KP Performance 880 MHz to 960 MHz Yagi Antenna, 9 dBi, 36in LMR400 pigtail coax with Type N Female Connector
- SKU: KP-960SPY9
- Manufacturer: KP Performance
- Data Sheet: Download
Product Information
KP Performance KP-960SPY9
880 MHz to 960 MHz Yagi Antenna, 9 dBi, 36in LMR400 pigtail coax with Type N Female Connector, Adjustable Polarization Pro-Series
The KP Performance KP-960SPY9 880 MHz to 960 MHz Yagi Antenna is designed for the most rugged conditions and ships the same day. Equipped with an N-Female connector, coaxial connections to a radio are simple and easy. This 900 MHz antenna provides 9 dBi of gain and adjustable polarization. The KP-960SPY9 is ideally suited for 900 MHz ISM bands. This 9 dBi antenna supports Land Mobile Radio for land transportation, utility, manufacturing, and petrochemical companies (oil and gas).
Measuring 24.3 inches long, the N-female KP-960SPY9 from KP Performance is manufactured using robust 5/16” aircraft quality aluminum elements. The KP-960SPY9 elements are completely welded to a 1” boom and painted black. This ensures performance and survivability in the toughest environments.
KP-960SPY9 Yagi Antenna from KP Performance operating from 880 MHz to 960 MHz can cover all your needs for Land Mobile Radio and Utilities communications.
KP Performance 9 dBi 900 MHz 24.3 inch Yagi antennas are high-quality components backed by expert technical support and sales personnel. The KP-960SPY9 is in stock and ready to ship the same day.
Features:
- Aircraft Quality 6061-T6 Aluminum with 5/16’’ Elements with 360° Fully Welded to a 1’’ Boom
- Powder-Coated Balck for Corrosion, Fade, and Ice-Build Up Resistance
- Can be Installed for Either Vertical or Horizontal Polarization
- Comes with 36’’ LMR400 Pigtails with N-Type Female Connectors
Applications:
- 900 MHz Cellular and GSM
- 900 MHz ISM Band & Wireless LAN Systems
- Point to Multipoint & Non Line of Sight
- NLOS Applications
- RFID & SCADA
- LPWAN, LoRA, IoT, M2M
Specifications
Specifications KP-960SPY9
Frequency Range | 880 MHz to 960 MHz |
Polarization Type | Horizontal or Vertical |
Gain | 9 dBi |
Vertical Beamwidth | 50° |
Horizontal Beamwidth | 60° |
F/B Ratio | 15 dB |
VSWR | 1.5:1 |
Connector Type | Type N Female |
Length | 24.3 in |
Width | 7.1 in |
Height | 2.4 in |
Mounting Mast Daimeter | 0.75 to 2 in |
Weight | 3 lbs (1.36 kg) |
