KP Performance 2 GHz 24 dBi Dual Pol Feed Horn Antenna - 4 Pack Box

US$‎645.76 US$‎679.75
  • SKU: KPPA-24-2GHZDPFHA-4P
  • Manufacturer: KP Performance
  • Data Sheet: Download
  • Installation Guide: Download
  • Availability: 23 In Stock    (updated live)
    23 In stock at Lewisville TX
US$‎645.76 US$‎679.75

KP Performance KPPA-24-2GHZDPFHA-4P (4 Pack)

2 GHz 24 dBi Dual Pol Feed Horn Antenna with Large Dish (4 Pack Box)

The KPPA-24-2GHZDPFHA-4P 2 GHz dual-polarized feed horn reflector dish antennas are the ideal solution for point-to-point and customer premises equipment (CPE) applications. They are also a better alternative to traditional flat panel antennas. This 2 GHz feed horn antenna has an adjustable bracket that allows for vertical/horizontal or ±45-degree slant polarization schemes and delivers 24 dBi gain. This feedhorn antennas operate in the 2.3-2.7 GHz frequency range and provides VSWR as low as 1.5:1. It can be used with radios from Cambium, UBNT, MikroTik or any other 2 GHz dual-connectorized radio.

These feed horn reflector dish antennas deliver a 32 dB front-to-back and port isolation greater than 30 dB and cross-polarization discrimination greater than 20 dB. This 28" dish antenna features two Type-N female connectors and a J-arm pole mount. These antennas are built to sustain high-winds and resist sun-fade and rusting. They can also be special ordered with a company logo added to the dish face.


Features:

  • Powder coated to prevent salt and sun fade
  • Comes in a 4 pack for cost effective shipping and handling
  • Sleek design, allowing these to be installed on clients homes for a higher gain
  • Low wind loading for mounting on towers for point to point shots
  • This dish can also utilize a Canopy Claw mount, Nanostation and Loco radio mounts.

Specifications KPPA-24-2GHZDPFHA-4P

Frequency Range2.3 GHz to 2.7 GHz
Polarization Type
H/V or 45 Deg. Slant
Gain24 dBi
Vertical Beamwidth11.6°
Horizontal Beamwidth11.6°
F/B Ratio32dB
VSWR1.5:11
Cross Polar Ratio26 dB
Port Isolation20 dB
Connector Type2 x Type N Female
