Mean Well 48V 600W 12.5A High Reliability IP65 LED Power Supply

(0) No Reviews yet
  • SKU: HLG-600H-48A
  • Manufacturer: Mean Well
  • Data Sheet: Download
  • Availability: 1 In Stock (updated live)
$208.72

Specifications HLG-600H-48A

Input Voltage 90~305Vac
C.V. Output Voltage 48.0 Volts
C.V. Max Current 12.500 Amps
Max Output Power 600 Watts
Constant Current 12.500 Amps
C.C. Voltage Min 24.00 Vdc
C.C. Voltage Max 48.00 Vdc
ACCESSORIES:
32V86S 6' North American AC Cord
CJ04-1 LED PSU Cable Joiner 14-16AWG
CJ04-2 LED PSU Cable Joiner 18-22AWG
SPD-20-277P 277VAC/20kA Surge Protection

Mean Well HLG-600H-48A

48V 600W 12.5A High Reliability IP65 LED Power Supply

HLG-600H series is a 600W AC/DC LED driver featuring the dual mode constant voltage and constant current output. HLG-600H operates from 90 305VAC and offers models with different rated voltage ranging between 12V and 54V. Thanks to the high efficiency up to 96%, with the fanless design, the entire series is able to operate for -40°C~+90°C case temperature under free air convection. The design of metal housing and IP67/IP65 ingress protection level allows this series to fit both indoor and outdoor applications. HLG-600H is equipped with various function options, such as dimming methodologies, so as to provide the optimal design flexibility for LED lighting system.


Features:

  • MEAN WELL HLG-600H-48A constant voltage and constant current LED power supply
  • Full range AC input: 90~305Vac
  • Operating case temperature: -40~+90°C
  • Safety approval: UL60950-1
  • UL8750 type HL LED power supply
  • Meet 4kV surge immunity level (IEC61000-4-5)
  • Built-in active PFC
  • vIP65 durable aluminium enclosure
  • High efficiency
  • Output voltage and constant current level can be adjusted through internal potentiometers
  • Protections: short circuit / over current / over voltage / over temperature
  • Applications: LED electric display, lighting, LED street lighting and indoor/outdoor lighting
  • MEAN WELL 7 year warranty
