TP-Link 16-Port 10/100 Mbps + 2-Port Gigabit Rackmount Switch with 16-Port PoE+
Product Information
TP-Link TL-SL1218MP
16-Port 10/100 Mbps + 2-Port Gigabit Rackmount Switch with 16-Port PoE+
High PoE Power Budget
TL-SL1218MP complies with the 802.3af/at PoE+ standard, supporting up to 30W power supply on each PoE port. The total high PoE power budget of up to 192W for the 16 PoE ports, making it ideal for small to medium business surveillance systems.
Up to 250m Transmission for Surveillance
TL-SL1218MP is a special designed PoE switch for IP surveillance applications. PoE switch makes surveillance installation simpler, safer and less expensive. With the extend mode, the PoE transmission distance reaches up to 250m* which makes it perfect for IP Camera deployment in large area coverage.
Video Quality Guaranteed
Priority mode guarantees the important data, such as video surveillance, delivered with the best priority passing the data fabric even when the traffic load is heavy. Hardware switch for easy configuration with no login required.
Easy to Use
- Plug & play, no configuration required
- Auto MDI/MDIX eliminates the need for crossover cables
- Auto-negotiation intelligently adjusts for compatibility and optimal performance
Features:
- 16 PoE+ 10/100Mbps RJ45 ports, 2 Gigabit RJ45 ports and 2 combo Gigabit SFP slots
- Up to 250m data and power transmission under extend mode specially designed for surveillance system
- Priority mode for port1-8 to guarantees the quality of sensitive applications like video monitor
- High PoE power budget with up to 30W for each PoE port and 194W for all PoE ports
- Easy to use, with no configuration and installation needed
Specifications
Specifications TL-SL1218MP
| General | |
| Interfaces | 16 10/100Mbps RJ45 Ports 2 10/100/1000Mbps RJ45 Ports 2 Gigabit SFP Slots |
| PoE | |
| PoE Standard | 802.3af/at |
| PoE Ports | 16, up to 30W |
| PoE Power Budget | 192W |
| Performance | |
| Switching Capacity | 7.2Gbps |
| Packet Forwarding Rate | 5.36Mpps |
| MAC Address Table | 8K |
| Packet Buffer | 4.1Mbit |
| Jumbo Frame | 10KB |
| Physical & Environment | |
| Power Supply | 100-240V AC, 50/60Hz |
| Max Power Consumption | 217.22W (with 192W PD Connected) 18.73W (no PD Connected) |
| Max Heat Dissipation | 741.15 BTU/h (with 192W PD Connected) 63.91 BTU/h (no PD Connected) |
| Dimensions (W × D × H) | 17.3 × 7.1 × 1.7 in.(440 × 180 × 44 mm) |
| Fan Quantity | 2 |
| Operating Temperature | 0°C~40°C (32°F~104°F) |
| Storage Temperature | -40°C~70°C (-40°F~158°F) |
| Operating Humidity | 10%~90%RH non-condensing |
| Storage Humidity | 5%~90%RH non-condensing |
| Certification | CE, FCC |
