Tycon Power 170W Complete Solar Kit with 30A MPPT Controller, 12/24V

US$‎788.45 US$‎829.95
  • SKU: TPSK12/24M-170W
  • Manufacturer: Tycon Systems
  • Data Sheet: Download
  • User Guide: Download
  • Availability: 247 In Stock    (updated live)
    247 In stock at Utah
US$‎788.45 US$‎829.95

Tycon Power TPSK12/24M-170W

170W 12V or 24V Solar Kit: Qty 2 85W Panels, Pole Mount, MPPT Controller, Cables, Supports 40W continuous

The TPSK series of solar panel kits come complete with high efficiency multicrystalline solar panel, side of pole/wall mounts, PWM Charge Controller and outdoor rated 12AWG cable. They are ready for quick connection to Tycon Power® outdoor UPSPro® Systems or any other application requiring solar power. The panels provide excellent low light performance and long life (25years). The rugged aluminum frame and high transparency, low iron, tempered glass withstands high wind, hail and snow loading. The mounts are heavy duty aluminum with stainless steel hardware. They are a simplified design that makes them easy to install, saving precious installer time. The mounts are designed for pole mounting but can also be wall mounted. They provide quick tilt adjustment for positioning the panel to proper sun angles for summer and winter sun.


  • Complete Kit – Solar Panel, Pole/Wall Mount, Outdoor 12AWG Cable, Battery Charge Controller
  • Accommodates 2" to 4.5" dia. Pole or Wall Mountv
  • Quick tilt adjustment (15° to 65°)
  • Certified for up to 110MPH Winds


  • Remote Power Stations
  • Wireless Base Stations
  • Lighting Applications
  • Surveillance Applications

Specifications TPSK12/24M-170W

Solar Panel Voltage/Capacity12V/24V 160W
Solar Panel Max Current8.86A
Solar Panel Size26” x 68”
Solar Panel ModelTPS-12-80W x 2
Pole Diameter2” to 4.5”
Pole Mount ModelTPSM-80x4-UNI
Wind Speed Rating90MPH
Charge Controller ModelTP-SC24-20
Cable – 2 Cond – Outdoor12AWG x 20’
Operating Temperature-40C to +85C
Shipping Weight24kg (53lb)
System Self Consumption<1.5W
Battery TypeNon Spillable Sealed Lead Acid GEL
Battery Life (TYPICAL)5 Years
Enclosure TypePowder Coated Steel, Security Locks, Pole (2” to 4”) or Wall Mount
Enclosure External Size24 x 15 x 14" (610 x 381 x 356mm)
Enclosure Internal Size23 x 14 x 12" (584 x 356 x 305mm)
Operating Temperature-30°C to +60°C (-22°F to 140°F)
System Weight (without batteries)55lb (25kg)
Battery Weight37lb (17kg) each x 2
Warranty3 years
