SERIES
Integra-E
Freedom of capacity
10Gbps wireless fiber solution for fast, secure
deployment with AES 256 encryption
buy now
Integra-E Series
10Gbps capacity, security, high-reliability, carrier-grade features, & 5-year warranty
The Integra-E Series supports Adaptive Code Modulation & Bandwidth (ACMB), in which sets the coding rate, modulation, and bandwidth
changes are set in real-time based on the link’s conditions. This feature
enables a significant increase in payload capacity and link availability.
ACMB switching is hitless - the link stays locked, and data is transmitted
without errors. In addition, Integra E3 provides enhanced security with
AES 256-bit encryption. In most countries, E-band radios are easy to set
up with no or minimal licensing requirements, thus reducing deployment
time and Total Cost of Ownership (TCO). Integra-E Series is a high-
performance microwave radio communications system for top-quality,
high-capacity backhaul networks.
Freedom of capacity
Integra-E offers 10Gbps capacity, making
it a perfect wireless alternative to fiber.
Light licensing requirements
Save money by delivering higher capacity
with lower licensing costs.
depends on countries & regions
Advanced ethernet functionality
Ethernet functionality with 50Gbps
switching capacity.
5-year standard warranty
Upgrades and new features. Excellent 24/7
technical support and reliable capacity.
Adaptive code modulation & bandwidth
Significantly increases payload
capacity and link availability.
AES 256 enhanced security
Over-the-air encryption for added
security layer
Key Characteristics
| Integra-E2 | Integra-E3 | ||
|---|---|---|---|
| Capacity | Up to 2.2 Gbps at 2x 112 MHz 4096QAM |  | |
| Frequency bands | 6, 7, 8, 11, 13, 15, 18, 23 and 26 GHz. (All licensed bands up to 38 GHz*) | | |
| Max Modulation | 4096QAM | | |
| Channel Bandwidth | from 5 MHz up to 112 MHz | | |
| Configurations | 1+0, 2+0 XPIC, 2+0 ACAP, 2+0 ACCP*, 1+1 SD* | | |
| Gigabit Ethernet | 1xRJx45, 2xSFP+ | | |
| Management | Out-of-band, In-band, SNMP v1/2c/3, SSH, Telnet, HTTPS, Serial, RADIUS, Network Time Protocol | | |
| Encryption | AES 256 bit | | |
| Antenna | External antenna | | |
| Form factor | 280 x 437 x 100 mm / 11.02” x 17.2” x 3.9”, 8.5 kg / 18.7 lbs | | |
| Temperature range | -33 ... +55 °C / -28 … +130 °F | | |
