ADSS(All-Dielectric Self-Supporting)

Fiber Optic Cable Single Sheath
Fiber Optic cable

ADSS Single Sheath

The Fiber Optic cable Type ADSS (All-Dielectric Self-Supporting) Cable with a Single Sheath is engineered to excel in demanding applications, with a primary design focus on impressive spans of 100 to 200 meters (notably, specific models extend this to spans of up to 1,400 meters). This cable stands as a testament to its robust and dependable nature, delivering a dependable solution for high-speed data transmission. Its innovative structure has been meticulously crafted to provide optimal performance and exceptional durability, ensuring that it meets the highest standards of reliability in the field.

Structure Design

12-144F ITU-T G652D (A1 & A2 Glass options are available)

Loose tube containing fibers and filled with a suitable water
tightness filling compound

Loose tubes SZ stranded around CSM

Water blocking tape

Aramid Yarn

Highlights

Resistant to Environmental Factors

Withstand wind, ice, & temperature changes, expanding & contracting as needed.

Low Installation Cost

Cost-effective due to their self-supporting
design, ideal for challenging terrains.

Lightweight and Compact

Easy to handle thanks to their dielectric design.

Low Maintenance

Require minimal maintenance with their non-metallic construction.

Long-Haul Application

Long-haul telecommunications networks & remote or water-crossing locations.

Specification

fiber count1224364896144
Fiber Count Per Tube 6 6 6121212
Loose Tube Material PBT
Water Blocking Material Fiber Jelly
Counts2464812
Central Strength Member MaterialFRP Rod (Coated with PE if needed)
Counts2.22.22.22.52.52.5
Overall Diameter (nom.)(mm)(±0.2)10.310.410.41112.314.9
Outer Jacket MaterialHDPE, Black
Nominal Thickness (mm)1.61.61.61.61.61.6
Cable WeightKg/Km73767686109162
Temperature Range Operation -30°C~+70°C
Storage -30°C~+70°C
Installation-30°C~+70°C

Optical Characteristics

Attenuation Coefficient

@1310nm ≤ 0.35 dB/Km
@1550nm ≤ 0.21 dB/Km
*Full compliance with the ITU-T G.652D Standard

Mechanical Performance

Minimum bending radius Static 10D & 20D Dynamic (D is the cable diameter in mm)
