Flat Drop Fiber
Optic Cable 1-12F
Fiber Reinforced Plastic (FRP)
Fiber Optic cable
Flat Drop 1-12F
LiteLinx Flat Drop Cable is specifically engineered for a range of installation methods, including self-supporting, direct-buried, and duct setups. Its fully
dielectric design makes it an excellent choice for drop applications, ensuring convenient access and straightforward installation.
The cable incorporates two parallel dielectric strength members, eliminating the need for bonding or grounding, and providing outstanding crush resistance. Additionally, the FRP (Fiber Reinforced Plastic) strength members are coated with EAA to enhance their adhesion properties. Can be ordered as pre-connected, choose from 1 FO to 12 FO.
Structure Design
Central tube PBTFiber 1-12F ITU-T G657A1Central tube containing fibers and filled with a suitable water tightness filling compoundTow parrel FRP as reinforcementSheath HDPE
Highlights
Installation
Low friction installation
Resistance
Flexible and kink resistant
Termination
Rapid cable termination
Specification
| fiber count | 1-12F | |
| Strength Member | Material | PBT |
| Diameter (mm) | 3.0 | |
| Reinforcement Elements | Material | FRP |
| Size (mm) | 1.6 | |
| Outer Jacket | Material | HDPE |
| Thickness | 0.8mm | |
| Overall Diameter (nom.)(mm)(±0.2) | 4.5*8.1 | |
| Weight | Kg/Km | 37 |
| Temperature Range | Operation | -40°C~+60°C |
| Storage | -50°C~+70°C | |
| Installation | -20°C~+60°C |
Optical Characteristics
Attenuation Coefficient
| ≤ 0.36 dB/Km | @1310nm |
| ≤ 0.22 dB/Km | @1550nm |
*Full compliance with the ITU-T G.657.A1 standard
*Full compliance with the ITU-T G.657.A1 standard
Mechanical Performance
There is no leakage detected at the cable end during the Water Penetration Test according to IEC 60794-1-F5B.No jacket cracking or fiber breakage in Tensile Loading, Torsion, Crush/Impact Resistance, Repeated Bending, and Temperature Cycling tests per IEC Standards.
