Cambium PTP 820 2' ANT,SP,23GHz,RFU-C TYPE & UBR220
- SKU: N230082D042A
$969.15
- Manufacturer: Cambium Networks
Product Information
Cambium Networks N230082D042A
PTP 820 2' ANT,SP,23GHz,RFU-C TYPE & UBR220 - Radiowaves
Specifications
Specifications N230082D042A
| alpha frequency | 23 GHz |
| front-to-back ratio (dB) | 68 dB |
| mounting hdw included (Y/N) | N |
| maximum power input (W) | N/A |
| polarization | horizontal or vertical |
| lightning protection | DC ground |
| vertical tilt (deg) | 0 deg |
| antenna diameter (ft) | 2' |
| radome (Y/N) | N |
| antenna size range | 2 ft to 3 ft |
| frequency range | 21200-24890 |
| dB gain range | 40.0 + |
| gain | 40.2 dBi |
| frequency (bandwidth) | 21.2-23.6 GHz |
| VSWR | <1.37:1 |
| connector | RFU-C type & UBR220 |
| wind survival w/o ice (MPH) | 125 MPH |
| beamwidth (deg) | 1.7 deg |
| Depth | 31" |
| Width | 31" |
| Height | 25" |
| Weight | 48 LB |
