  • IgniteNet Metrolinq One 60Ghz PTP Radio, 19 cm

IgniteNet Metrolinq One 60Ghz PTP Radio, 19 cm

  • SKU: ML1-60-19-US
  • Manufacturer: IgniteNet
  • Data Sheet: Download
  • Availability: Direct Ship Item! Ships direct from manufacturer usually same day. Email me when this product is in stock!

IgniteNet ML1-60-19-US

IgniteNet MetroLinq 60GHz Outdoor PTP 2.4/5GHz w/Integrated 38dBi & 16dBi (5GHz) Antenna & 2.4GHz RPSMA

The IgniteNet MetroLinq™ One 60GHz PTP Radio, 19 cm is a Cloud-Enabled Outdoor 60GHz PTP + 5GHz + 2.4 GHz. The IgniteNet’s MetroLinq One 60 is the world’s first cost-effective high capacity 60GHz PTP radio enabling high performance, interferencefree connections worldwide. The MetroLinq™ One 60 has an added advantage of being license-free in most markets globally, allowing ultra fast deployment and without the hassle of other frequency bands requiring a license.

The MetroLinq™ One 60 also includes a second 5GHz radio which can be configured as PtP (backup) to provide integrated redundancy without and additional hardware or complexity and additional 2.4GHz radio for remote access and configuration or local Wi-Fi coverage.

Specifications ML1-60-19-US

Size190 x 190 x 120mm (7.48 x 7.48 x 4.72 in.)
Weight4.41 lb
Temperature Operating -30deg;C to 55deg;C (-22deg;F to 131deg;F) Storage -40deg;C to 70deg;C (-40deg;F to 158deg;F)
HumidityOperating 10% to 90% (non-condensing)
Ports ETH RJ-45 Port: 1000Base-T, passive PoE SFP Port: 1000Base-X
60GHz RadioProprietary
5GHz RadioIEEE 802.11ac
Radio Frequencies 5150 - 5250 MHz (FCC) 58.32 - 65.88 GHz
PoE24-48 VDC passive PoE
Power Consumption24W maximum
