KP Performance Cambium Radio Large Reflector Dish for 2 GHz, 3 GHz, 5 GHz Radios (4-Pack)

US$‎244.66 US$‎257.54
  • SKU: RK24EWIFIDBI-4LD
  • Manufacturer: KP Performance
  • Data Sheet: Download
  • Availability: 330 In Stock    (updated live)
    330 In stock at Lewisville TX
US$‎244.66 US$‎257.54

KP Performance RK24EWIFIDBI-4LD

KP Performance Cambium Radio Reflector Large Dish - 4 Pack Box

The KP Performance RK24EWIFIDBI-4LD is a 4-pack of our large 27.5" reflector dish antennas with a radio mount specially designed for Cambium Canopy FSK and 450 2 GHz, 3 GHz and 5 GHz radios.

SOLD IN 4 PACKS. 16 boxes fit on a pallet 52 x 30 x 70 inches.


Features:

  • Designed for 2 GHz, 3 GHz and 5 GHz.
  • These large Cambium dish kits will give you 2 to 3 dBi more gain over the standard size dish kits.

WIND LOADING SPECS

  • Wind Speed Load On Antenna Load (Newtons)
  • 60 Kmph 14.0 lbs 62.5 N
  • 80 Kmph 25.0 lbs 111.0 N
  • 100 Kmph 39.0 lbs 173.5 N
  • 120 Kmph 56.2 lbs 249.8 N
  • 140 Kmph 76.4 lbs 340.0 N

Specifications RK24EWIFIDBI-4LD

Electrical
Frequency Band 2GHz3GHz 5GHz
Reflector Gain 21±0.5 dBi23±0.5 dBi27±0.5 dBi
Polarization Slant or H/V Slant or H/V Slant or H/V
Horizontal HPBW 10 Degree7 Degree5 Degree
Vertical HPBW 13 Degree10 Degree7 Degree
Front to Back Ratio 23 dB 25 dB 25 dB

Mechanical
Electrical Grounding Reflector grounded to mounting bracket
Surface Finish UV resistant matt powder coat
Wind Load, frontal414N @ 140km/h | 93 lbf @ 87mph
Max. Wind Speed 160km/h | 100mph
Mounting TypeJ-Arm mount in kit
Reflector Dimensions
Dimension 29.5 in L x 25.5 in W x 8.5 in H
Weight 45 lbs
