Cambium 2.4 GHz PMP 450 Connectorized Access Point
- SKU: C024045A001A
- Manufacturer: Cambium Networks
- Data Sheet: Download
Product Information
Cambium Networks C024045A001A
2.4 GHz PMP 450 Connectorized Access Point
The Cambium Networks Point-to-Multipoint (PMP) 450 Access Point (AP) can provide more than 90 Mbps throughput and is interoperable with PMP 430 and PMP 100 Series Subscriber Modules (SM). Service providers with an installed base of PMP 100 subscribers can now migrate to new high-throughput PMP 450 modules to enhance overall capacity; allowing more users and/or higher rate plans.
Utilizing 2x2 MIMO-OFDM technology, new deployments can take advantage of Cambium Networks proprietary feature set, while achieving data rates higher than 90 Mbps. From the available synchronization options to its diverse feature set, the PMP 450 provides flexible deployment options that make it a good fit for high capacity, high reliability networks.
Cambium Networks provides exceptional wireless broadband connectivity solutions. With more than 3 million modules deployed in thousands of networks around the world, Cambium solutions are proven to provide cost effective, reliable data, voice and video connectivity.
Specifications
Specifications C024045A001A
| Channel Spacing | Configurable on 2.5 MHz increments |
| Frequency Range | 2400 - 2483.5 MHz |
| Channel Width | 5 MHz, 10 MHz or 20 MHz |
| Physical Layer | 2x2 MIMO OFDM |
| Ethernet Interface | 10/100/1000BaseT, half/full duplex, rate auto negotiated (802.3 compliant) |
| Subscribers per Sector | Up to 238 |
| Latency | 3 - 5 ms |
| Antenna Beam Width | 2.4 GHz - 60° SECTOR (DUAL SLANT) |
| Transmit Power Range | -30 TO +22 dBm (COMBINED, TO EIRP LIMIT BY REGION) (1 dB INTERVAL) (+23 dBm FOR 3 GHz) |
| Antenna Gain | 17 dBi DUAL SLANT (SECTOR ANTENNA AVAILABLE FOR 60°) |
| Max. Transmit Power | 22 dBm Combined |
| Antenna Connection | 50 ohm, N-TYPE |
| Environmental | IP67, IP66 |
| Temperature | -40°C TO +55°C (-40°F TO +131°F), 0-95% |
| Weight | 5.5lbs (2.5kg) |
| Wind Survival | 118mph (190km/hour) |
| Dimensions | 10.6" x 8.3" x 2.8" (27 x 21 x 7cm) |
| Max. Power Consumption | 18W |
| Input Voltage | 22 to 32 VDC |
